CUAV CAN PDB Power Distribution Board for FPV Drones

Introduction

The CUAV CAN PDB is a high-performance power distribution board designed for demanding FPV and UAV applications. It offers robust power delivery, precise monitoring capabilities, and flexible output options, making it an essential component for advanced drone builds. This board is engineered to solve common power management issues, ensuring stable and reliable operation even under heavy loads.

Key advantages

• Supports ultra-wide input voltage from 10V to 62V for maximum compatibility.
• Handles a continuous current of 180A, suitable for high-power systems.
• Accurately measures voltage and current, with 0.1A precision up to 110A.
• Provides 14 servo outputs for extensive control capabilities.
• Dual adjustable output interfaces offer 5V/6A and 12V/4A for peripherals.
• Utilizes extra-thick copper and tinned PCB to minimize heating under high current.
• Features an LED power indicator for visual LiPo voltage status.
• Extremely low voltage drop across 10 main power outputs.
• Advanced heat dissipation design with thick copper layers and window dimming.
• Offers a powerful 78W adjustable UBEC output, exceeding typical board capabilities.

Technical specifications

• Input Voltage: 10~62V ultra-wide
• Continuous Current: 180A
• Current Accuracy: 0.1A (up to 110A)
• Voltage Accuracy: 0.05V
• Servo Outputs: 14 channels
• Adjustable Output 1: 5V/6A
• Adjustable Output 2: 12V/4A
• PCB: Extra-thick copper, tinned
• Features: LED power indicator, low voltage drop outputs, advanced heat dissipation
• UBEC Output Power: 78W

Applications

This power distribution board is perfect for custom FPV racing drones, professional UAV platforms, aerial photography systems, and any drone project requiring stable and high-current power management. It's also suitable for complex robotic projects and industrial applications where precise power delivery is critical.

Compatibility

Compatible with a wide range of LiPo batteries from 3S to 14S. The dual adjustable outputs (5V/6A and 12V/4A) are designed to power various peripherals like flight controllers, FPV cameras, video transmitters, GPS modules, and servos.

FAQ

What is the CUAV CAN PDB and what are its main features?

The CUAV CAN PDB is an advanced power distribution board for FPV and UAV drones. Its key features include ultra-wide 10-62V input voltage, 180A continuous current handling, precise voltage and current monitoring, 14 servo outputs, and dual adjustable power outputs (5V/6A and 12V/4A).

What are the benefits of using the CUAV CAN PDB for my drone build?

Using the CUAV CAN PDB ensures stable and efficient power delivery to all your drone components. Its high current capacity, accurate monitoring, and robust construction with excellent heat dissipation minimize risks associated with power fluctuations and overheating, leading to improved performance and reliability.

What kind of accuracy does the CUAV CAN PDB offer for voltage and current measurements?

The CUAV CAN PDB provides highly accurate measurements. It offers a current accuracy of 0.1A up to 110A and a voltage accuracy of 0.05V, allowing for precise monitoring of your drone's power consumption.

Can the CUAV CAN PDB power multiple peripherals simultaneously?

Yes, the CUAV CAN PDB is equipped with 14 servo outputs and dual adjustable power outputs (5V/6A and 12V/4A). This allows it to efficiently power a wide range of peripherals such as flight controllers, cameras, video transmitters, and servos.

Where can I buy the CUAV CAN PDB with fast delivery?

You can buy the CUAV CAN PDB at HTDRONE, our specialized FPV drone parts store based in Poland. We offer fast international delivery via DHL, ensuring you receive your order quickly wherever you are.
