Caddx Eclipse 009CA Thermal FPV Camera 960x768 Pixelpump Gen3 for Drones

Introducing the Caddx Eclipse 009CA Thermal Camera

The Caddx Eclipse 009CA is a compact thermal imaging camera specifically engineered for integration into modern unmanned aerial platforms. Perfect as an FPV drone thermal camera or a general UAV thermal camera, it delivers a stable thermal picture in low-visibility conditions, making it an essential upgrade for professional and advanced hobbyist drone applications. Experience unparalleled thermal detail for critical missions.

Key Advantages

• Advanced Pixelpump Gen3 Technology: Delivers superior image detail and contrast with a 960x768 resolution for clearer thermal signatures.
• Enhanced Heat Source Distinction: Better differentiation of thermal targets, crucial for identification and analysis.
• Vibration Reduction: Minimizes image blur caused by drone vibrations, ensuring a stable, usable feed.
• Smooth FPV Experience: Provides a fluid thermal image even during dynamic FPV flight maneuvers.
• Dual Video Output: Supports both Analog PAL and Digital UVC outputs for flexible integration with your FPV system or ground station.
• Adjustable Image Settings: Fine-tune brightness, contrast, color palettes, digital zoom (1.0-4.0×), and image rotation (H/V/diagonal) for optimal viewing.
• Compact and Energy Efficient: Features small dimensions (35.2×26.2×46.4 mm) and low power consumption (< 2W), ideal for weight-sensitive drone builds.
• Wide Operating Temperature: Functions reliably in temperatures ranging from -20°C to +50°C.

Technical Specifications

• Model: Eclipse 009CA
• Resolution: 960×768 (Pixelpump)
• Frame Rate: 50 Hz
• Video Output: PAL + UVC
• Voltage: 4.5-24 V
• Power Consumption: < 2 W
• Focal Length: 9.1 mm
• Aperture: F1.0
• FOV: 48.3° (H) × 38.6° (V)
• Zoom: 1.0-4.0×
• Operating Temperature: -20°C ~ +50°C
• Dimensions: 35.2×26.2×46.4 mm

Applications

This thermal camera is perfectly suited for a wide range of demanding applications including reconnaissance missions, search and rescue operations, technical infrastructure inspections, and various specialized professional uses where clear thermal visibility is critical. It excels in FPV racing, long-range exploration, and security surveillance.

Compatibility

The Caddx Eclipse 009CA offers versatile compatibility with its dual PAL and UVC outputs. It operates within a wide voltage range of 4.5-24 V and can be configured via UVC or ADKEY for seamless integration into most FPV and UAV systems. Its compact size ensures easy mounting on various drone frames.

FAQ

What is the Caddx Eclipse 009CA thermal camera best suited for?

The Caddx Eclipse 009CA is ideal for FPV drones and UAV platforms used in reconnaissance, search and rescue operations, technical inspections, and other specialized applications requiring clear thermal imaging in limited visibility conditions.

What are the key technical features of the Caddx Eclipse 009CA?

It boasts a 960x768 resolution powered by Pixelpump Gen3 technology, offering enhanced detail and contrast. It supports dual PAL and UVC video outputs, has a 50Hz frame rate, and operates within a 4.5-24V range with low power consumption (< 2W).

How does the Pixelpump Gen3 technology benefit the image quality?

Pixelpump Gen3 technology significantly improves image quality by providing higher contrast, better detail, improved heat source distinction, and reduced motion blur. This results in a smoother and clearer thermal image, especially during dynamic FPV flight.

Where can I buy the Caddx Eclipse 009CA thermal camera with fast delivery?

You can buy the Caddx Eclipse 009CA thermal camera at HTDRONE. We offer fast and reliable international delivery via DHL to ensure you receive your order promptly.

What is the operating temperature range for the Caddx Eclipse 009CA?

The Caddx Eclipse 009CA thermal camera is designed to operate reliably in a wide temperature range, from -20°C up to +50°C, making it suitable for various environmental conditions.
