CaddxFPV Ascent GT Pro VRX Receiver Module for Ascent HD System

Introduction

The CaddxFPV Ascent GT Pro VRX is a professional-grade ground video receiver designed specifically for the Ascent HD System. It provides pilots with a stable, high-definition 1080p video feed and operates across an ultra-wide frequency band of 4.90-6.40 GHz. This module is engineered for FPV enthusiasts who prioritize reliability, image clarity, and near-zero latency, integrating advanced features like automatic channel switching, DVR recording, and real-time telemetry into a compact, field-ready unit.

Key Advantages

• Ultra-wide 4.90-6.40 GHz frequency range ensures stable reception from all Ascent HD VTX devices, even in busy environments.
• 42 selectable channels allow for quick switching between drones without signal interference or delays.
• High-resolution 1080p/60fps HDMI output provides a crisp video feed for FPV goggles, monitors, or broadcast setups.
• Advanced Auto-hopping function automatically finds the cleanest channel and adjusts bandwidth (2.5/5/10/20/40 MHz) for optimal stability.
• Built-in DVR records live flights directly to a microSD card (up to 256GB) for post-flight review and analysis.
• Real-time telemetry displays crucial flight data including voltage, bitrate, signal strength, latency, and SD card status.
• Intuitive 5D joystick control allows for easy navigation of settings without needing a computer.
• Wide voltage input (7.4-25.2V) ensures easy integration with various ground stations and goggle setups.

Technical Specifications

• Communication Frequency: 4.90~6.40 GHz
• Transmitter Power (EIRP): 5.8 GHz: < 35 dBm, FCC: <20 dBm, CE <14 dBm, SRRC: <20 dBm
• Transmission Bandwidth: 2.5/5/10/20/40 MHz
• Input/Output Interface: HDMI, MicroSD Card, DC5.5x2.1mm
• HDMI Output: 1080P60/50fps, 720P60/50fps
• Power Input: 7.4~25.2 V
• Memory: MicroSD card up to 256 GB
• Channels: 42
• Output Power: 4000 mW
• Auto Frequency Hopping: Supported
• Auto Bandwidth: Supported
• System: Ascent HD System
• VRX Weight: 117.9 g
• VRX Dimensions: 114.3 x 64 x 24 mm
• Antennas: LHCP RP-SMA (Red Bird, 2 dBi)
• Antenna Model: Red Bird
• Antenna Polarization: LHCP
• Antenna Bandwidth: 5.6 GHz-6.0 GHz
• Antenna Average Gain: 2 dBi
• Antenna Radiation Efficiency: >97%
• Antenna VSWR: <1.3
• Antenna Cross-Polarization Rejection: -15 to -30 dB
• Antenna Connector: RP-SMA x2
• Antenna Dimensions: 24.8 x 15.3 mm
• Antenna Weight: 3.5 g

Applications

This VRX module is ideal for FPV drone racing, freestyle flying, aerial cinematography, and any application requiring high-quality, low-latency video transmission within the CaddxFPV Ascent HD ecosystem. It's perfect for pilots flying in complex environments or those who need reliable real-time video feedback for precise control.

Compatibility

Fully compatible with CaddxFPV Ascent HD VTX units, Ascent/Cine goggles, and Avatar HD cameras. Supports wide voltage input from 7.4V to 25.2V, making it versatile for various setups. Features HDMI output for external displays and microSD card support for recording.

FAQ

What is the CaddxFPV Ascent GT Pro VRX Receiver Module?

The CaddxFPV Ascent GT Pro VRX is a professional ground video receiver designed for the Ascent HD System. It provides stable, high-definition 1080p video with low latency and features like DVR recording and real-time telemetry.

What is the operating frequency range of the Ascent GT Pro VRX?

This receiver module operates on an ultra-wide frequency band from 4.90 GHz to 6.40 GHz, offering 42 selectable channels for stable reception even in crowded FPV environments.

Does the CaddxFPV Ascent GT Pro VRX have a DVR function?

Yes, the Ascent GT Pro VRX features a built-in DVR that allows you to record your live FPV flights directly onto a microSD card, supporting capacities up to 256 GB for post-flight analysis.

What is the video output resolution and frame rate?

The module supports HDMI output at resolutions of 1080p at 60fps and 720p at 60fps, ensuring a clear and smooth video feed for your FPV goggles or monitors.
