Diatone C25MK2 4S PNP-TX500 White Cinewhoop FPV Drone

Introduction

The Diatone C25MK2 4S PNP-TX500 (White) is a high-performance 2.5-inch Cinewhoop FPV drone from Diatone. Engineered with a durable 360° protective structure, it ensures maximum safety for its components and surroundings thanks to its fully enclosed propellers. This drone is designed for pilots who prioritize safety without compromising on flight performance, making it an excellent choice for both experienced FPV enthusiasts and those looking to get into the Cinewhoop segment. Available in multiple colors, this white version offers a sleek aesthetic.

Key Advantages

• Durable 360° protective design for enhanced safety.
• Fully enclosed propellers for maximum component and environment protection.
• Equipped with reliable CADDX Baby Ratel 2 camera and MAMBA TX500 VTX.
• Powerful MAMBA TOKA 1404 4000KV motors for agile flight.
• Integrated MAMBA AIO F722 MK1 flight controller and 35A ESC for smooth control.
• Compact 2.5-inch propeller size ideal for Cinewhoop flight characteristics.
• Includes various mounting brackets for accessories like Insta360 GO2 and CADDX PEANUT.
• Ready for a 4S Lipo battery (650-850mAh recommended) for extended flight times.

Technical Specifications

• Name: C25MK2 4S PNP-TX500
• Color: White
• Camera: CADDX Baby Ratel 2
• Antenna: MAMBA ULTRA RHCP
• VTX: MAMBA TX500
• FC: MAMBA AIO F722 MK1
• ESC: 35A 8BIT
• Motor: MAMBA TOKA 1404 4000 KV
• Propeller Size: 2.5 inch
• Recommended Lipo Size (not included): 4S 650-850mAh
• Wheelbase: 111.5mm
• Weight: 130g
• Included Accessories: 1x C25MK2 main bracket, 2x 8mm camera damping bracket, 1x Insta360 GO2 mounting bracket, 1x CADDX PEANUT mount, 1x GF D63 Propeller, 1x Buzzer, 2x Battery strap, 1x M2 screw mounting kit, 1x 20mm PC insulating board.

Applications

The Diatone C25MK2 is a versatile Cinewhoop drone suitable for a wide range of applications including smooth cinematic FPV flying, aerial videography, indoor FPV, freestyle piloting, and general UAV operations where a compact and protected drone is desired. Its robust design makes it a great choice for learning and practicing FPV skills.

Compatibility

This PNP (Plug and Play) drone is designed to work with standard FPV components. It requires a 4S LiPo battery with a capacity of 650-850mAh for optimal performance. The included accessories offer mounting options for popular action cameras like the Insta360 GO2 and CADDX PEANUT, allowing for high-quality aerial recording.

FAQ

What is the Diatone C25MK2 4S PNP-TX500 drone best suited for?

The Diatone C25MK2 4S PNP-TX500 is a 2.5-inch Cinewhoop FPV drone ideal for cinematic FPV flying, aerial videography, and general freestyle use. Its durable 360° protective design makes it safe for indoor use and around people.

What LiPo battery is recommended for the Diatone C25MK2 4S PNP-TX500?

For optimal performance and flight time, a 4S LiPo battery with a capacity between 650mAh and 850mAh is recommended for the Diatone C25MK2 4S PNP-TX500. Batteries are sold separately.

Does the Diatone C25MK2 4S PNP-TX500 come with a camera?

Yes, the Diatone C25MK2 4S PNP-TX500 comes equipped with a CADDX Baby Ratel 2 camera, known for its excellent performance in various lighting conditions.

Where can I buy the Diatone C25MK2 4S PNP-TX500 drone?

You can buy the Diatone C25MK2 4S PNP-TX500 drone directly from HTDRONE. We offer fast shipping within Poland and reliable delivery to Ukraine via Nova Poshta, as well as worldwide shipping via DHL.

What are the key protection features of this Cinewhoop drone?

The Diatone C25MK2 features a robust 360° design with fully enclosed propellers. This design significantly enhances safety by protecting the propellers from damage and preventing them from causing harm or damage to surroundings.
