Diatone Roma F35 Vista HD 4S FPV Drone - Freestyle Quadcopter

Introduction

The Diatone Roma F35 Vista HD 4S is a high-performance 3.5-inch FPV quadcopter built for advanced freestyle flying. It combines a robust Diatone Roma F35 frame with the cutting-edge Caddx Vista HD digital FPV system and potent MAMBA TOKA 2203.5 motors, delivering an immersive and dynamic flight experience. This ready-to-fly (without receiver) drone is perfect for pilots seeking agility, speed, and stunning HD footage.

Key Advantages

• Powerful Propulsion: Equipped with MAMBA TOKA 2203.5 4200KV motors for exceptional thrust and responsiveness.
• HD Digital FPV: Features the Caddx Vista system, providing clear, low-latency HD video transmission.
• Durable Construction: Built with a robust Diatone Roma F35 3.5" frame using high-quality 7075 Aluminum Alloy and T300 3K Carbon Fiber.
• Optimized for 4S: Designed to run on 4S LiPo batteries (850-1000mAh recommended) for balanced power and flight duration.
• Advanced Flight Controller: Utilizes the MAMBA DJI F722 MINI MK2 flight controller for stable and precise flight characteristics.
• High-Quality Components: Includes MAMBA ULTRA LHCP antenna and MAMBA F40BLS_MINI ESC for reliable operation.
• Ideal for Freestyle: The 3.5-inch size and powerful setup make it perfect for performing complex aerial maneuvers.

Technical Specifications

• Model Name: Roma F35 Vista HD 4S (No Receiver)
• Camera: Nebula Pro
• Antenna: MAMBA ULTRA LHCP
• VTX: CADDX VISTA
• Flight Controller (FC): MAMBA DJI F722 MINI MK2
• Electronic Speed Controller (ESC): MAMBA F40BLS_MINI
• Motor: MAMBA TOKA 2203.5 4S (4200 KV)
• Weight: 215g (without battery)
• Frame: Diatone Roma F35 3.5"
• Rated Voltage: 4S
• Wheelbase: 158mm
• Propeller Size: 3.5 inch
• FC Mounting: 20x20mm (M2/M3) / 30.5x30.5mm (M3)
• Motor Mounting: 12mm (M2) / 16mm (M3)
• Camera Mount Spacing: 19mm/20mm
• Max Stack Height: 25mm
• Top Plate Thickness: 2mm
• Bottom Plate Thickness: 3mm
• Arm Thickness: 3mm
• Materials: 7075 Aluminum Alloy, T300 3K Carbon Fiber
• Included Accessories: GF 3520 Propeller Set, Buzzer, Battery Straps (2x), M2 Screw Accessory Kit, M3 Screw Accessory Kit, 20mm PC Spacer

Applications

This FPV drone is primarily designed for freestyle FPV flying, allowing pilots to perform intricate aerial acrobatics. Its HD digital system also makes it suitable for capturing high-quality aerial footage during casual flights or creative videography.

Compatibility

The drone features standard FC and motor mounting options (20x20mm, 30.5x30.5mm for FC; 12mm, 16mm for motors) and supports a 19mm/20mm camera spacing. It requires a 4S LiPo battery (850-1000mAh recommended, not included). It is designed to work with DJI compatible FPV systems.

FAQ

What is the Diatone Roma F35 Vista HD 4S FPV drone best suited for?

The Diatone Roma F35 Vista HD 4S is specifically designed for freestyle FPV flying, allowing pilots to perform advanced maneuvers and tricks. Its powerful setup and HD digital video system also make it suitable for capturing dynamic aerial footage.

What battery is recommended for the Diatone Roma F35 Vista HD 4S?

For optimal performance and flight times of approximately 6-7 minutes, a 4S LiPo battery with a capacity between 850mAh and 1000mAh is recommended. Please note that the battery is not included with the drone.

Does the Diatone Roma F35 Vista HD 4S come with a receiver?

No, this version of the Diatone Roma F35 Vista HD 4S is sold without a receiver, allowing you to choose and install your preferred radio receiver system.

Where can I buy the Diatone Roma F35 Vista HD 4S FPV drone with fast delivery?

You can buy the Diatone Roma F35 Vista HD 4S FPV drone at HTDRONE. We offer fast international shipping via DHL, ensuring you receive your order quickly.

What are the key components included with the Diatone Roma F35 Vista HD 4S?

The drone comes with essential accessories including a GF 3520 propeller set, a buzzer, battery straps, and various screw accessory kits for mounting. It features a Nebula Pro camera, MAMBA F722 MINI MK2 FC, and MAMBA F40BLS_MINI ESC.
