Diatone Roma F35 Vista HD 4S FPV Drone with TBS Receiver for Freestyle Flying

Introduction

The Diatone Roma F35 Vista HD 4S is a high-performance 3.5-inch FPV drone designed for thrilling freestyle flying. Featuring a cutting-edge Caddx Vista HD system and powerful MAMBA TOKA 2203.5 motors, this quadcopter delivers an exceptional FPV experience. It comes integrated with a TBS CRSF receiver, making it ready for advanced control setups. This drone is the perfect choice for pilots seeking agility, power, and HD video transmission for their freestyle maneuvers.

Key Advantages

• Exceptional Freestyle Performance: Engineered for dynamic FPV flying with a 3.5-inch prop size and powerful motors.
• Integrated HD FPV System: Features the Caddx Vista VTX and Nebula Pro camera for crystal-clear, low-latency HD digital video transmission.
• Reliable TBS Receiver: Comes with a TBS CRSF receiver for robust and responsive control.
• Powerful Drivetrain: Equipped with MAMBA TOKA 2203.5 4200KV motors for impressive thrust and speed.
• Durable Construction: Built with a robust Diatone Roma F35 frame using premium 7075 aluminum alloy and T300 3K carbon fiber.
• Optimized for 4S Power: Designed to work with 4S LiPo batteries (850-1000mAh recommended) for extended flight sessions.
• High-Quality Components: Includes MAMBA DJI F722 MINI MK2 FC and MAMBA F40BLS_MINI ESC for stable and reliable flight control.
• Complete Package: Comes with essential accessories like GF 3520 propellers, buzzer, and battery straps.

Technical Specifications

• Product Name: Roma F35 Vista HD 4S (TBS Receiver)
• Camera: Nebula Pro
• Antenna: MAMBA ULTRA LHCP
• VTX: CADDX VISTA
• Flight Controller (FC): MAMBA DJI F722 MINI MK2
• Electronic Speed Controller (ESC): MAMBA F40BLS_MINI
• Motor: 4S MAMBA TOKA 2203.5 (4200 KV)
• Weight: 215g
• Receiver: TBS CRSF
• Frame: Diatone Roma F35 3.5"
• Rated Voltage: 4S
• Wheelbase: 158mm
• Propeller Size: 3.5 inch
• FC Mounting: 20x20mm (M2/M3) / 30.5x30.5mm (M3)
• Motor Mount: 12mm (M2) / 16mm (M3)
• Camera Mount: 19/20mm
• Max Stack Height: 25 mm
• Top Plate: 2 mm
• Bottom Plate: 3mm
• Arm: 3 mm
• Material: 7075 Aluminum Alloy, T300 3K Carbon Fiber

Applications

This FPV drone is primarily designed for freestyle flying, offering a thrilling and agile experience. It's also suitable for cinematic FPV flights where HD video quality is essential, and general UAV hobbyist use for advanced pilots.

Compatibility

Power: Recommended 4S LiPo battery with 850-1000mAh capacity. Rated voltage is 4S.

Mounting: Features flexible FC mounting options (20x20mm M2/M3 and 30.5x30.5mm M3) and standard motor mounts (12mm M2 / 16mm M3). Camera mounting supports 19/20mm spacing.

Receiver: Includes a TBS CRSF receiver, compatible with TBS Crossfire and Tracer radio transmitters.

FAQ

What is the recommended battery for the Diatone Roma F35 Vista HD 4S drone?

For optimal performance and flight times of approximately 6-7 minutes, a 4S LiPo battery with a capacity of 850-1000mAh is recommended for the Diatone Roma F35 Vista HD 4S.

What FPV system does the Diatone Roma F35 Vista HD 4S use?

The Diatone Roma F35 Vista HD 4S is equipped with the Caddx Vista VTX system and a Nebula Pro camera, providing high-definition digital FPV transmission for a clear and immersive flying experience.

Does the Diatone Roma F35 Vista HD 4S come with a receiver?

Yes, this version of the Diatone Roma F35 Vista HD 4S includes a TBS CRSF receiver, ensuring reliable and responsive control for your FPV flights.

Where can I buy the Diatone Roma F35 Vista HD 4S FPV drone?

You can buy the Diatone Roma F35 Vista HD 4S FPV drone at HTDRONE. We offer fast shipping within Poland and worldwide delivery via DHL, ensuring you receive your order quickly.

What type of flying is the Diatone Roma F35 Vista HD 4S best suited for?

The Diatone Roma F35 Vista HD 4S is specifically designed for freestyle FPV flying, offering the power, agility, and HD video capabilities needed for dynamic aerial maneuvers.
