FLYWOO GOKU F722 F722 Pro Mini V2 45A 32Bit 128K AM32 Stack for FPV Drones

Introduction

The FLYWOO GOKU F722 Pro Mini V2 Stack is a premium 20x20 flight controller and ESC (Electronic Speed Controller) combination designed for advanced FPV and UAV pilots. It addresses the need for robust, high-performance components that deliver precise control and reliability in demanding flight conditions. This stack is optimized for freestyle and long-range builds, providing a seamless integration experience for modern FPV systems.

Key advantages

• High-performance STM32F722 MCU for superior processing power.
• Advanced ICM42688 gyro ensures stable and accurate flight control.
• Integrated 16MB blackbox for detailed flight data logging.
• AM32 firmware on the 45A ESC provides smooth, responsive motor control with 128KHz PWM frequency.
• Wide 2-6S LiPo battery compatibility for versatile build options.
• Designed for plug-and-play connectivity with DJI O3 Air Unit and other peripherals.
• Compact 20x20 mounting size, ideal for smaller, high-performance drone builds.
• Robust design with reliable power delivery (10V/2A BEC, 5V/2A BEC).

Technical specifications

• Flight Controller (FC):
• Firmware (BF): FLYWOO F722PROV2
• Firmware (INAV): FLYWOO F722PRO
• MCU: STM32F722
• Gyroscope: ICM42688
• OSD: AT7456E
• Barometer: DPS310 / SPL06
• Blackbox: 16 MB
• UART: 1 / 2 / 3 / 4 / 5 / 6
• Input Voltage: 7.4V - 26V (2-6S LiPo)
• BEC: 10V 2A / 5V 2A
• Size: 32 × 29 × 20 mm
• Mounting Holes: M2 20 × 20 mm
• Weight: 9.9 g
• ESC:
• Name: GOKU G45M 4-in-1
• Firmware: GOKU_F4A32_PRO
• Supported Firmware: AM32
• Supported Protocols: DShot300 / DShot600 / DShot1200
• PWM Frequency: 24K - 128KHz
• Input Voltage: 2-6S LiPo
• Continuous Current: 45A

Applications

This FPV stack is perfect for building high-performance freestyle drones, long-range exploration vehicles, and competitive racing quadcopters. Its advanced features and robust performance make it suitable for pilots looking to push the limits of their FPV experience.

Compatibility

The FLYWOO GOKU F722 Pro Mini V2 Stack is compatible with 2-6S LiPo batteries. It features multiple UART ports for various peripherals and includes specific connectors for plug-and-play integration with the DJI O3 Air Unit, receivers, and cameras. The 20x20mm mounting pattern ensures compatibility with most modern FPV frames.

FAQ

What is the FLYWOO GOKU F722 Pro Mini V2 Stack?

The FLYWOO GOKU F722 Pro Mini V2 Stack is a high-performance combination of a 20x20 flight controller and a 45A 32-bit ESC, designed for advanced FPV drone builds. It features an STM32F722 MCU and AM32 firmware for smooth, responsive control.

What are the key technical specifications of this FPV stack?

This stack includes an STM32F722 MCU, ICM42688 gyroscope, 16MB blackbox, and a 45A continuous current ESC with AM32 firmware supporting up to 128KHz PWM frequency. It operates on 2-6S LiPo batteries and offers multiple UART ports.

What kind of FPV drones is this stack suitable for?

The FLYWOO GOKU F722 Pro Mini V2 Stack is ideal for freestyle FPV drones and long-range exploration vehicles. Its robust performance and advanced features make it suitable for pilots seeking precision and reliability.

Does this FPV stack support DJI O3 Air Unit?

Yes, the FLYWOO GOKU F722 Pro Mini V2 Stack is designed for plug-and-play compatibility with the DJI O3 Air Unit, simplifying your FPV build process.

Where can I buy the FLYWOO GOKU F722 Pro Mini V2 45A Stack?

You can order the FLYWOO GOKU F722 Pro Mini V2 45A 32Bit AM32 Stack directly from HTDRONE. We offer fast shipping within Poland and reliable worldwide delivery via DHL.
