RunCam Nano 2 FPV Analog Camera 2.1mm Lens 700TVL for Racing Drones

Introduction

The RunCam Nano 2 is a top-tier analog FPV camera designed for the demanding world of drone racing and freestyle. As one of the smallest and best performing cameras available, its nano dimensions (14x14mm) make it exceptionally versatile for compact builds where space is at a premium. If you're searching for an unparalleled nano-sized FPV camera, the RunCam Nano 2 is your ultimate choice, offering excellent WDR capabilities and clarity.

Key advantages

• Ultra-compact nano size (14x14mm) for versatile mounting options.
• Exceptional WDR performance for clear images in challenging lighting conditions.
• High resolution of 700TVL ensures sharp and detailed video feed.
• Wide 155° Field of View (FOV) for an immersive FPV experience.
• Lightweight design, weighing only 3.2g, ideal for performance-focused builds.
• Durable ABS casing for reliable operation.
• Easy integration with standard FPV systems.
• Reliable performance with a wide operating voltage range (3-5.5V).

Technical specifications

• Model: RunCam Nano 2
• Image Sensor: 1/3" CMOS
• Horizontal Resolution: 700TVL
• Lens: 2.1mm (M8)
• Field of View (FOV): 155°
• Signal System: PAL/NTSC (Non-switchable)
• Signal to Noise Ratio: >50dB
• Electronic Shutter Speed: Auto
• Automatic Gain Control (AGC): Auto
• Min. Illumination: 0.01Lux@1.2F
• D-WDR: Auto
• Day/Night: Color
• Power Supply: DC 3-5.5V
• Power Consumption: 110mA@5V, 120mA@3.3V
• Housing Material: ABS
• Net Weight: 3.2g
• Dimensions: L14mm*W14mm*H16mm

Applications

This camera is specifically designed for FPV racing drones, freestyle quadcopters, and other small UAV applications where a compact, lightweight, and high-quality analog video feed is essential. It excels in dynamic FPV environments.

Compatibility

Features a standard M8 lens mount and DC power input (3-5.5V), making it compatible with most FPV flight controllers and power distribution boards. The non-switchable PAL/NTSC system ensures broad compatibility with analog FPV goggles and video transmitters.

FAQ

What is the RunCam Nano 2 camera best suited for?

The RunCam Nano 2 is best suited for FPV racing and freestyle drones due to its ultra-compact nano size, lightweight design, and excellent video quality with WDR. It's ideal for pilots who need a high-performance analog camera for demanding aerial maneuvers.

What are the key technical specifications of the RunCam Nano 2?

The RunCam Nano 2 features a 1/3" CMOS sensor, 700TVL horizontal resolution, a 2.1mm lens with a 155° FOV, and operates on DC 3-5.5V. It weighs only 3.2g and has dimensions of 14x14mm.

Does the RunCam Nano 2 have switchable video standards (PAL/NTSC)?

No, the RunCam Nano 2 features a non-switchable signal system, meaning it operates on either PAL or NTSC by default. Ensure compatibility with your FPV goggles or video receiver before purchasing.

What is the power consumption of the RunCam Nano 2?

The RunCam Nano 2 has a power consumption of 110mA at 5V and 120mA at 3.3V, making it an energy-efficient choice for FPV drone builds.

Where can I buy the RunCam Nano 2 FPV camera with fast delivery?

You can buy the RunCam Nano 2 FPV camera at HTDRONE. We offer fast shipping within Poland and reliable worldwide delivery via DHL, ensuring you get your parts quickly.
