Foxeer F722 V4 Mini Pro FPV Flight Controller 20x20mm 2-6S Lipo Support | Best Deal

Introduction

The Foxeer Mini F722 V4 Pro FPV Flight Controller is a compact yet feature-rich solution for modern FPV drone builds. Engineered with a 20x20mm mounting pattern, it's perfectly suited for smaller drone frames where space is at a premium. This flight controller provides the power and control needed for agile and responsive flight, making it an excellent choice for both beginners and experienced pilots looking to optimize their setups. It integrates essential features like Pit PASS and ample memory for flight logs.

Key Advantages

• Compact 20x20mm mounting size, ideal for smaller FPV drone frames.
• Supports a wide 2-6S Lipo input voltage range for versatile power options.
• Equipped with 4x UART sets for extensive peripheral connectivity.
• Built-in Pit PASS functionality for enhanced safety and control.
• 16MB Flash memory for Blackbox logging to analyze flight data.
• Onboard BF OSD for real-time flight information display.
• Smart Audio support for easy configuration and control.
• Lightweight design at only 4.4g, minimizing impact on drone weight.

Technical Specifications

• Model: Mini F722 V4 Pro
• CPU: STM32F722RET6
• Power Input: 2-6S Lipo (6.5V-30V)
• BEC Output: DC5V/3A
• OSD: BF OSD
• Blackbox: 16M Flash memory
• UART: 4 sets
• ESC Telemetry: RX4
• Buzzer: Yes
• Smart Audio: Yes
• LED: 1 set 2812 LED
• USB: Micro USB
• Firmware: FOXEERF722V4
• Size: 28.5 * 28.5 mm
• Mounting Hole: 20x20mm, Φ4mm
• Weight: 4.4g
• Operating Temperature: -20°C - +55°C
• Operating Humidity: 20-95%
• Storage Temperature: -20°C - +70°C

Applications

This flight controller is primarily designed for FPV (First Person View) drones, including freestyle quads, racing drones, and compact cinematic builds. Its robust feature set also makes it suitable for custom UAV projects requiring precise control and data logging.

Compatibility

The Foxeer Mini F722 V4 Pro is compatible with 2-6S Lipo batteries. It features 4 UART ports for connecting various peripherals such as GPS modules, receivers, and ESC telemetry. The 20x20mm mounting pattern ensures compatibility with a wide range of smaller FPV drone frames. It uses a Micro USB port for configuration.

FAQ

What is the Foxeer F722 V4 Mini Pro Flight Controller?

The Foxeer F722 V4 Mini Pro is a compact FPV flight controller with a 20x20mm mounting pattern, designed for smaller drone frames. It supports 2-6S Lipo batteries and features 4 UART ports, 16MB Blackbox memory, and Pit PASS functionality.

What are the main advantages of the Foxeer F722 V4 Mini Pro?

Key advantages include its compact size for smaller builds, wide 2-6S Lipo voltage support, multiple UARTs for connectivity, onboard OSD, and Blackbox memory for flight analysis. Its lightweight design is also beneficial.

What is the recommended application for this flight controller?

This flight controller is ideal for FPV drones, including freestyle, racing, and small cinematic builds. Its feature set makes it suitable for pilots looking for reliable performance and advanced control options.

Where can I buy the Foxeer F722 V4 Mini Pro flight controller with fast delivery?

You can buy the Foxeer F722 V4 Mini Pro flight controller at HTDRONE. We offer fast shipping within Poland and reliable worldwide delivery via DHL, ensuring you get your FPV parts quickly.

What is the power input range for the Foxeer F722 V4 Mini Pro?

The Foxeer F722 V4 Mini Pro supports a wide power input range from 2-6S Lipo batteries, which translates to approximately 6.5V to 30V. This allows for flexible power configurations in your drone build.
