Foxeer Mini Night Cat 4 1200TVL Analog FPV Camera for Racing & Freestyle

Introduction

The Foxeer Mini Night Cat 4 is a high-performance analog FPV camera engineered for drone pilots who require exceptionally clear and reliable video feeds across all lighting conditions. Whether you're engaged in intense FPV racing, dynamic freestyle maneuvers, or building compact aerial platforms, this camera delivers outstanding image quality and robust performance. Its advanced features and compact form factor make it an ideal choice for discerning pilots.

Key Advantages

• Superior Image Quality: Equipped with a high-quality Sony 1/3" CMOS sensor, it captures sharp, detailed video with excellent color reproduction.
• Exceptional Low-Light Performance: Boasts impressive sensitivity, providing a clear image even in challenging low-light environments, with rapid adaptation to changing light conditions.
• Wide Dynamic Range: Features a 100dB WDR, ensuring balanced exposure and detail in both bright highlights and deep shadows simultaneously.
• Vibrant Color & Contrast: Delivers natural color rendition and sharp contrast for confident flight and precise navigation.
• Flexible Configuration: Offers switchable aspect ratios (4:3/16:9) and video systems (PAL/NTSC) for versatile setup options.
• Integrated OSD Menu: Built-in On-Screen Display allows for easy in-flight adjustments and camera customization.
• Compact & Lightweight: The mini form factor (22x22mm, 11.8g) is ideal for tight spaces and weight-sensitive builds.
• Durable Design: Built to withstand the demands of FPV flying, ensuring reliability.

Technical Specifications

• Sensor Type: Sony 1/3" CMOS sensor
• Aspect Ratio: 4:3 (Default) / 16:9 Switchable
• TV System: PAL (Default) / NTSC Switchable
• Resolution: 1200 TVL
• Lens: M12 2.1mm Low Light Lens
• Field of View (FOV):
  4:3 FOV-H: 95°, FOV-V: 72°, FOV-D: 120°
  16:9 FOV-H: 95°, FOV-V: 53°, FOV-D: 110°
• Shutter Speed: PAL 1/25~1/10000 s; NTSC 1/30~1/10000 s
• Video Output: Analog CVBS Signal
• Minimum Illumination: 0.00001 Lux
• White Balance: Auto
• DNR: 3DNR
• WDR: 100 dB
• DAY/NIGHT Mode: EXT/Auto/Color/Black & White
• Flight OSD: Voltage/Camera Title/Time
• Input Voltage: 5V~20V
• Language Support: ENGLISH /中文/ PYCCKNN / ESPANOL / ITALIANO /FRANCAIS/POLSKIM/ PORTUGUES / 日本语 / EAAHNIKA
• Operating Temperature: -10°~50°C RH90% MAX
• Operating Humidity: 20~80%
• Storage Temperature: -20°~70°C
• Power Consumption: 95mA±15% @ DC12V
• Dimensions: 22 x 22 mm
• Weight: 11.8 g (without cable)

Applications

This camera is ideally suited for FPV racing drones, freestyle FPV setups, compact drone builds, and any application where a high-quality, reliable analog video feed is essential, especially in variable lighting conditions.

Compatibility

The Foxeer Mini Night Cat 4 is compatible with a wide range of FPV systems supporting analog CVBS video output and requires an input voltage between 5V and 20V. Its standard 22x22mm mounting size ensures compatibility with most FPV frames. The included OSD board and cables facilitate easy integration.

FAQ

What is the best FPV camera for low light conditions?

The Foxeer Mini Night Cat 4 is an excellent choice for low-light FPV flying. It features a highly sensitive Sony CMOS sensor with a minimum illumination of 0.00001 Lux and advanced 3DNR processing, ensuring a clear and visible image even in very dark environments.

What are the key features of the Foxeer Mini Night Cat 4?

This camera offers 1200TVL resolution, a Sony 1/3" CMOS sensor, excellent low-light performance, 100dB WDR, switchable 4:3/16:9 aspect ratios, and PAL/NTSC systems. It also includes an integrated OSD menu for easy adjustments and a compact 22x22mm form factor.

Is the Foxeer Mini Night Cat 4 suitable for FPV racing drones?

Yes, the Foxeer Mini Night Cat 4 is ideal for FPV racing due to its clear image quality, fast response, and compact, lightweight design (11.8g). Its robust performance in various lighting conditions ensures reliable video feedback during races.

What is the video output of the Foxeer Mini Night Cat 4?

The Foxeer Mini Night Cat 4 outputs an analog CVBS signal, which is standard for most FPV video transmitters and goggles. This ensures broad compatibility with existing FPV setups.

Where can I buy the Foxeer Mini Night Cat 4 FPV camera with fast delivery?

You can buy the Foxeer Mini Night Cat 4 FPV camera directly from HTDRONE. We are based in Poland and offer fast shipping within Poland and reliable worldwide delivery via DHL for international customers.
