GEPRC Crocodile4 Baby HD BNF FPV Drone with Wasp & TBS Nano RX F7 Flight Controller

Introduction

The GEPRC Crocodile4 Baby HD is a high-performance 4-inch FPV drone designed for extended long-range flights. It combines a lightweight frame with a powerful propulsion system, offering pilots an exceptional flying experience with an impressive flight time exceeding 28 minutes. Available in both DJI HD VTX and Analog VTX versions, this drone is perfect for pilots who demand endurance and advanced features.

Key Advantages

• Exceptional Flight Endurance: Achieve over 28 minutes of flight time on a single charge, perfect for long-range exploration.
• Powerful Propulsion: Equipped with the newly developed GEPRC 1404 2750kv motors and Gemfan 4024 propellers for stable and efficient flight.
• Advanced Flight Control: Features the new GEP-F7-35A AIO flight controller with STM32F722RET6 MCU and a 6-axis gyroscope for precise handling.
• High-Definition FPV Feed: Integrated DJI HD VTX system delivers crystal-clear video transmission for immersive FPV flying.
• Integrated GPS Module: Offers GPS functionality for enhanced navigation and safety, including a Betaflight emergency rescue mode.
• Lost Drone Recovery: Includes GEPRC Finder with an audible alarm to help locate the drone if power is lost or the battery disconnects.
• Durable Frame Design: Built with a robust GEP-CB4 frame featuring carbon fiber plates of varying thicknesses for optimal strength and weight.
• Easy Control Feel: The combination of high-performance components ensures a stable flight and an intuitive, easy-to-control experience.

Technical Specifications

• Brand: GEPRC
• Model: Crocodile Baby 4″ HD
• Frame: GEP-CB4
• Wheelbase: 174 mm
• Top Plate Thickness: 1.5mm
• Bottom Plate Thickness: 2.0mm
• Arm Plate Thickness: 2.5mm
• Connector: XT30
• Flight Controller System: GEP-F7-35A (new AIO)
• MCU: STM32F722RET6
• Gyroscope: 6-Axis
• USB Interface: Type-C
• OSD: BetaFlight OSD with AT7456E chip
• Filter: Integrated LC filter
• Power Input: 4S LiPo
• VTX: Caddx Vista (for HD version)
• Propellers: Gemfan 4024
• Antenna: GEPRC Momoda 5.8g Long Version LHCP Antenna
• Motors: GR1404 2750KV
• GPS: GEP-M10
• Weight: 242g (excluding battery)
• Receiver: TBS Nano RX
• Recommended Motors: GR1404 2750KV
• Recommended Battery: 4S 650mAh - 1300mAh LiPo or 4S 3000mAh Li-ion

Applications

This FPV drone is ideal for long-range exploration, aerial photography, freestyle flying, and endurance testing. Its GPS functionality and rescue mode make it suitable for beginners and experienced pilots looking for a reliable platform for extended missions.

Compatibility

Compatible with 4S LiPo batteries (650mAh - 1300mAh) or 4S Li-ion batteries (3000mAh). Features a TBS Nano RX receiver for reliable control link. Uses an XT30 connector for power. The DJI HD VTX system ensures compatibility with DJI goggles.

FAQ

What is the maximum flight time of the GEPRC Crocodile4 Baby HD FPV drone?

The GEPRC Crocodile4 Baby HD FPV drone is designed for extended flights and can achieve over 28 minutes of flight time on a single charge with a recommended 4S battery.

Does the GEPRC Crocodile4 Baby HD include GPS functionality?

Yes, this FPV drone features an integrated GEP-M10 GPS module. This allows for enhanced navigation and includes a Betaflight emergency rescue mode to help return the drone to its approximate takeoff location if the signal is lost.

What FPV video transmission system does the GEPRC Crocodile4 Baby HD use?

The GEPRC Crocodile4 Baby HD comes equipped with the Caddx Vista system for high-definition digital FPV video transmission, providing a clear and immersive flying experience when paired with compatible DJI goggles.

What type of receiver is included with the GEPRC Crocodile4 Baby HD?

This GEPRC FPV drone comes with a pre-installed TBS Nano RX receiver, ensuring a reliable and robust radio control link for precise flight control.

Where can I buy the GEPRC Crocodile4 Baby HD FPV drone with fast delivery?

You can order the GEPRC Crocodile4 Baby HD FPV drone from HTDRONE. We offer fast shipping within Poland and reliable delivery to Ukraine via Nova Poshta, as well as worldwide shipping via DHL.
