GEPRC GEP-F722-35A AIO Flight Controller & ESC - High-Performance FPV Builds

Introduction

The GEPRC GEP-F722-35A AIO is an all-in-one flight controller and Electronic Speed Controller (ESC) unit designed for FPV and UAV enthusiasts. It combines high performance with essential features in a compact and lightweight package, making it an excellent choice for building or upgrading a wide range of drone frames. This unit simplifies your build by integrating two critical components into one board.

Key Advantages

• High-Performance MCU: Features an STM32F722 MCU for superior processing power and speed.
• Ample UART Ports: Provides 5 full UART ports for easy connection of external peripherals like GPS, receivers, and VTX control.
• DJI Air Unit Compatibility: Includes a dedicated 6-pin connector for seamless plug-and-play integration with DJI Air Unit modules.
• Powerful ESC: The BLHeli_S 35A ESC handles continuous 35A current (40A burst) and supports 2-6S LiPo batteries, offering robust power delivery.
• Integrated Features: Supports OSD parameter adjustment, buzzer, and LED control for enhanced functionality and customization.
• Advanced IMU: Equipped with a BMI270/42688 gyroscope/accelerometer for stable flight performance.
• Onboard BlackBox: Features 16Mb of BlackBox memory for flight data logging and analysis.
• Compact and Lightweight: Designed with a 32x32mm board size and a 25.5x25.5mm mounting pattern, weighing only 8.8g.

Technical Specifications

• Model Name: GEP-F722-35A AIO
• MCU: STM32F722
• IMU: BMI270/42688 (SPI) Gyroscope/Accelerometer
• Firmware Target: GEPRC_F722_AIO
• OSD: Betaflight OSD with AT7456E
• UART Ports: R1 T1 / R2 T2 / R3 T3 / R4 T4 / R5 T5
• Buzzer: Yes
• LED: Yes
• USB: Micro USB
• BEC Output: 5V @ 1A
• Filter: Integrated LC Filter
• ESC MCU: 8BB21F16G
• Continuous Current: 35A
• Burst Current: 40A (10s)
• Input Voltage: 2-6S LiPo
• ESC Protocol Support: Dshot600, Oneshot, Multishot
• BlackBox: 16Mb
• Target: G_H_30
• Board Size: 32x32mm
• Mounting Hole: 25.5x25.5mm
• Weight: 8.8g

Applications

This AIO flight controller and ESC is perfect for building high-performance FPV freestyle drones, racing drones, cinematic FPV rigs, and custom UAV platforms. Its versatility makes it suitable for both experienced pilots and ambitious hobbyists looking to push the limits of their builds.

Compatibility

The GEPRC GEP-F722-35A AIO is compatible with 2-6S LiPo batteries and features a 6-pin connector for the DJI Air Unit Module. It uses a standard 25.5x25.5mm mounting pattern, ensuring compatibility with a wide variety of FPV drone frames. The unit also includes a 5V BEC output for powering accessories.

FAQ

What is the GEPRC GEP-F722-35A AIO?

The GEPRC GEP-F722-35A AIO is an integrated flight controller and 35A ESC unit designed for FPV and UAV drones. It features a powerful STM32F722 MCU and supports 2-6S LiPo batteries, making it ideal for high-performance builds.

What are the key technical specifications of the GEP-F722-35A AIO?

Key specs include an STM32F722 MCU, BMI270/42688 IMU, 35A continuous ESC current (40A burst), 2-6S LiPo support, 5 UART ports, 16Mb BlackBox, and a 5V@1A BEC output. It has a 25.5x25.5mm mounting pattern.

Is this AIO compatible with DJI Air Units?

Yes, the GEPRC GEP-F722-35A AIO features a dedicated 6-pin connector for plug-and-play compatibility with DJI Air Unit modules, simplifying your digital FPV build.

What type of drones is the GEP-F722-35A AIO suitable for?

This AIO is best suited for building custom FPV freestyle drones, racing drones, and smaller UAV platforms where a lightweight, high-performance, and integrated solution is desired.
