GEPRC MARK4-LR7 Analog ELRS 915MHz Long Range FPV Drone

Introduction

The GEPRC MARK4-LR7 Analog is a high-performance FPV drone engineered for long-range exploration and reliable video transmission. This 7-inch quadcopter combines a classic, attractive design with cutting-edge components, making it suitable for experienced pilots who demand stability, power, and extended flight times. Whether you're venturing far off or simply want a dependable platform, the MARK4-LR7 offers a superior FPV experience.

Key Advantages

• Classic and attractive design for a premium look and feel.
• High-power RAD 5.8G 1.6W VTX ensures a stable and reliable video signal over long distances.
• Powerful GEPRC E2806.5 1350KV motors, recommended for 6S batteries, provide high output power for dynamic flight.
• Stable performance with GEPRC F405 V2 flight controller and SPAN 50A BLHeli_S ESC for comfortable and responsive handling.
• Clear visual experience thanks to the integrated Caddx H1 camera.
• Extended flight times of 12-30 minutes with recommended batteries, allowing for longer missions.
• Integrated ELRS 915MHz receiver for robust and reliable control link.

Technical Specifications

• Model: MARK4 7-inch FPV
• Frame: GEP-MK4-7
• Wheelbase: 295 mm
• Top Plate: 3mm
• Bottom Plate: 3mm
• Arm Plate: 5mm
• Rail Plate: 2 mm
• FC: GEPRC F405 V2
• ESC: SPAN 50A BLHeli_S
• MCU: STM32F405RGT6
• Gyro: ICM-42688-P
• OSD: Betaflight OSD with AT7456E chip
• VTX: GEPRC RAD 5.8G 1.6W
• Camera: Caddx H1
• Antenna: Momoda 5.8G RHCP RP-SMA 120mm
• Motor: GEPRC E2806.5 1350KV
• Propeller: Gemfan 7037-3
• Weight: 455g (without battery)
• Receiver: ELRS 915
• Recommended Battery: Lipo 6S 2600mah-4200mah / Lion 6S 6000mah
• Flight Time: 12-30 minutes

Applications

This FPV drone is primarily designed for long-range flying, aerial exploration, and extended observation missions. Its robust build and powerful components also make it suitable for freestyle FPV flying where stability and consistent signal are crucial.

Compatibility

The drone is designed to work with 6S Lipo or Lion batteries (2600mAh-4200mAh for Lipo, 6000mAh for Lion). It features an integrated ELRS 915MHz receiver, ensuring compatibility with ExpressLRS control systems.

FAQ

What is the GEPRC MARK4-LR7 Analog FPV drone best suited for?

The GEPRC MARK4-LR7 Analog is best suited for long-range FPV flights and aerial exploration. Its robust design, powerful motors, and stable video transmission make it ideal for extended missions and reliable performance.

What type of battery is recommended for the GEPRC MARK4-LR7 Analog?

For optimal performance, it is recommended to use a 6S Lipo battery with a capacity between 2600mAh and 4200mAh, or a 6S Lion battery with a capacity of 6000mAh.

What is the flight time of the GEPRC MARK4-LR7 Analog drone?

With the recommended battery configurations, the GEPRC MARK4-LR7 Analog can achieve flight times ranging from 12 to 30 minutes, allowing for extended flight sessions.

Does the GEPRC MARK4-LR7 Analog come with an ELRS receiver?

Yes, the GEPRC MARK4-LR7 Analog comes equipped with an integrated ELRS 915MHz receiver, ensuring a reliable and robust control link for your flights.

Where can I buy the GEPRC MARK4-LR7 Analog FPV drone with fast delivery?

You can buy the GEPRC MARK4-LR7 Analog FPV drone at HTDRONE. We offer fast shipping within Poland and reliable delivery to Ukraine via Nova Poshta, as well as worldwide shipping via DHL.
