GEPRC MK5D-LR7 Analog GPS PNP FPV Drone - Long Range, 7-Inch

Introduction

The GEPRC MK5D-LR7 Analog GPS PNP is an advanced 7-inch FPV drone, meticulously upgraded from the popular MARK5 model. Designed for pilots who demand extended flight capabilities and reliability, this drone excels in long-range missions. It offers a stable and powerful platform for capturing high-quality aerial footage or engaging in immersive FPV flights, solving the need for a durable, high-performance drone capable of going the distance.

Key advantages

• Enhanced durability with an optimized arm structure and stylish aluminum alloy side lens mounts.
• Integrated Bluetooth for convenient wireless parameter tuning via your mobile phone.
• Superior flight stability and reduced vibrations due to a unique frame shock absorption design and independent capacitor/buzzer compartments.
• Versatile mounting options for various action cameras including full GoPro, Naked GoPro 8, Insta 360 GO2, and Caddx Peanut for stable, clear recordings.
• Extended flight times: up to 30 minutes with a GEP-VTC6-6000mAh battery, and 20 minutes with a GoPro 10.
• Powerful propulsion system featuring SPEEDX2 2806.5 1350KV motors and HQ Prop 7X4X3 propellers.
• High-performance GEPRC SPAN F722-BT-HD V2 flight controller with ICM 42688P gyro for smooth and redundant flight control.
• Equipped with a new compact GEPRC M8U GPS module for reliable long-range navigation.

Technical specifications

• Model: MK5D-LR7
• Frame: GEP-MK5D-LR7
• Dimensions: 230mm×350mm
• Wheelbase: 335mm
• Top Plate Thickness: 2.5mm
• Bottom Plate Thickness: 2.5mm
• Arm Plate Thickness: 6.0mm
• FC System: SPAN F722-BT-HD V2
• MCU: STM32F722
• Gyro: ICM 42688-P (SPI)
• OSD: BetaFlight OSD with AT7456E chip
• ESC: SPAN G50A BLHeli_32 4IN1 50A 4-6S ESC
• Propeller: HQ Prop 7X4X3 tri-blade propeller
• Motor: SPEEDX2 2806.5 1350KV (6S version)
• GPS: GEP-M10
• Antenna: Momoda 5.8G RHCP MMCX90 100MM
• Weight: 570g (MK5D-LR7 Analog version includes 3D printed parts)
• Receiver Version: PNP
• Recommended Battery: LiPo 6S 6000mAh (6S version)

Applications

This drone is ideal for long-range FPV flights, aerial photography, videography, and extended UAV missions. Its robust design and GPS capabilities make it suitable for exploring remote areas and conducting detailed aerial surveys.

Compatibility

Compatible with a wide range of action cameras, including full GoPro, Naked GoPro 8, Insta 360 GO2, and Caddx Peanut, thanks to its versatile mounting options. Supports LiPo 6S batteries. PNP version requires a compatible radio transmitter and receiver setup.

FAQ

What is the GEPRC MK5D-LR7 Analog GPS PNP drone best suited for?

The GEPRC MK5D-LR7 Analog GPS PNP drone is best suited for long-range FPV flights, aerial photography, and extended UAV missions. Its robust construction and GPS capabilities make it ideal for exploring remote areas and capturing high-quality footage over long distances.

What is the maximum flight time of the GEPRC MK5D-LR7?

With a GEP-VTC6-6000mAh battery, the GEPRC MK5D-LR7 can achieve up to 30 minutes of flight time. When carrying a GoPro 10, the flight time is approximately 20 minutes, offering excellent endurance for various applications.

Does the GEPRC MK5D-LR7 support wireless tuning?

Yes, the GEPRC MK5D-LR7 features built-in Bluetooth, allowing for convenient wireless parameter tuning directly from your mobile phone. This enhances the ease of setup and adjustments.

What action cameras can be mounted on the GEPRC MK5D-LR7?

The drone offers versatile mounting options and can accommodate a full range of GoPro cameras, Naked GoPro 8, Insta 360 GO2, and Caddx Peanut. This ensures stable and clear recording capabilities for your aerial footage.
