GEPRC GEP-LC7 Crocodile7 Long-Range FPV Drone Frame 7-inch

Introduction

The GEPRC GEP-LC7 Crocodile7 is a premium 7-inch FPV drone frame meticulously designed for demanding long-range flights and endurance missions. Built for stability and resilience, this frame is the perfect foundation for your next long-distance FPV rig, offering ample space and robust construction to handle powerful components and extended flight times. Experience unparalleled flight performance with this expertly engineered frame from GEPRC.

Key advantages

• Engineered for long-range FPV flights with a 315mm motor-to-motor size for maximum stability.
• Accommodates both 6-inch and 7-inch propellers for versatile performance tuning.
• Features versatile mounting options for FPV cameras, including support for 30.5x30.5mm and 20x20mm stacks.
• Integrated TPU protection for FPV cameras and GPS modules ensures component safety during flight.
• Constructed with durable 5mm thick arms for exceptional resilience against impacts.
• Generous internal space for easy integration of all your electronic components.
• Includes dedicated mounting for GPS modules (22x20mm).
• High-quality build from GEPRC, a trusted name in FPV drone frames.

Technical specifications

• Frame Name: GEP-LC7 Crocodile7
• Motor-to-motor size: 315 mm
• Arm thickness: 5 mm
• Top Plate thickness: 2.5 mm
• Bottom Plate thickness: 2.5 mm
• Camera Mount Width: 19 mm
• GPS Mount Size: 22 x 20 mm
• FC Mounting Holes: 30.5 x 30.5 mm and 20 x 20 mm
• Weight: 153g
• Recommended Propellers: 6-7 inches
• Recommended Batteries: 6S 2200mAh - 6S 2600mAh
• Recommended Motors: 2207 (1500-1700KV), 2306 (1500-1700KV), 2407 (1300-1700KV)
• Recommended ESC: 40A-60A
• Recommended Flight Controller: F7/F4/F3/Kiss/RF

Applications

The GEPRC GEP-LC7 Crocodile7 frame is ideal for long-range FPV exploration, aerial photography, cinematic FPV, endurance flying, and advanced freestyle piloting where stability and flight time are paramount. It's also suitable for drone racing setups requiring large propellers for high-speed performance.

Compatibility

This frame is designed to be compatible with a wide range of FPV cameras, including popular models like RunCam Split 2S, RunCam Split Mini 2, Foxeer Mix, and Caddx Turtle, thanks to its dual mounting hole pattern (30.5x30.5mm and 20x20mm). It supports various flight controllers and ESCs, and is optimized for 6S battery configurations with capacities ranging from 2200mAh to 2600mAh.

FAQ

What is the GEPRC GEP-LC7 Crocodile7 frame best suited for?

The GEPRC GEP-LC7 Crocodile7 frame is specifically designed for long-range FPV flights and endurance missions. Its large 315mm size and robust construction provide excellent stability, making it ideal for extended aerial exploration and cinematic FPV.

What size propellers can I use with the GEPRC GEP-LC7 Crocodile7 frame?

This frame is compatible with both 6-inch and 7-inch propellers. This flexibility allows pilots to choose the best propeller size for their specific flight requirements, whether it's for efficiency, speed, or maneuverability.

What flight controllers and FPV cameras are compatible with this GEPRC frame?

The GEPRC GEP-LC7 Crocodile7 frame features mounting holes for both 30.5x30.5mm and 20x20mm flight stacks, ensuring compatibility with most F4, F7, Kiss, and RF flight controllers. It also supports various FPV cameras like RunCam Split and Caddx Turtle.

How durable is the GEPRC GEP-LC7 Crocodile7 frame?

The frame is built for durability with 5mm thick arms and 2.5mm top and bottom plates. It also includes TPU protective elements for the FPV camera and GPS module, enhancing its resilience against impacts and rough landings.
