HTDRONE Mini2 640x512 FPV Thermal Camera for Drones & Inspection

Introduction

The HTDRONE Mini2 640x512 is a cutting-edge, uncooled thermal imaging camera specifically engineered for FPV drones, advanced inspection systems, and industrial monitoring. Featuring a high-performance Vanadium Oxide detector, it delivers superior thermal resolution (640x512) with remarkable detail and a sensitivity of 25 mK, ensuring precise detection of temperature variations. Its compact and lightweight form factor, combined with versatile video interfaces and a wide operating temperature range, makes it the ideal choice for demanding aerial applications and embedded systems.

Key Advantages

• High-resolution 640x512 thermal imaging with 12 μm pixel size for exceptional clarity.
• Sensitive, uncooled Vanadium Oxide infrared detector for precise temperature anomaly detection.
• Smooth 30/60 Hz refresh rate ensures real-time thermal visualization without lag.
• Multiple color palettes (white hot, black hot, etc.) for varied viewing preferences.
• Continuous 1.0-8.0x digital zoom and image mirroring for flexible observation.
• Dual non-uniformity correction methods (shutter and non-shutter algorithms) for consistent image quality.
• Supports multiple analog and digital video output formats for broad compatibility.
• Ultra-lightweight (<8.6g) and compact design optimized for FPV and drone integration.</li>
• Robust performance in extreme temperatures, resistant to vibrations and shocks.

Technical Specifications

• Detector Type: Uncooled Vanadium Oxide infrared detector
• Resolution: 640x512
• Effective Refresh Rate: 30/60 Hz
• Pixel Size: 12 μm
• Spectral Band: 8-14 μm
• NETD: 25 mK @ 25°C, F#1.0, 25 Hz
• Thermal Time Constant: <12 ms
• Non-uniformity Correction: Shutter / Non-shutter algorithm correction
• Brightness/Contrast Adjustment: 0~100, optional
• Polarization/Palette: White hot/Black hot/Various palettes support
• Digital Zoom: 1.0~8.0x continuous (step size: 0.1)
• Image Flipping: Vertical/Horizontal/Diagonal
• Analog Video Output: PAL/NTSC
• Digital Video Output: DVP/BT656/USB2.0/MIPI
• Communication Interface: UART/I2C/USB2.0
• Power Input: 5 V
• Typical USB Output Power Consumption @ 25°C: <0.7 W
• Weight (without lens): <8.6 g
• Dimensions (without lens): 21 x 21 x 10.3 mm
• Operating Temperature: -40 °C to +80°C
• Storage Temperature: -50°C to +85°C
• Humidity: 5%-95%, non-condensing
• Vibration: 6.06 g random vibration, all axes
• Shock: 80 g, 4 ms half-sine wave, three axes and six directions

Applications

This versatile thermal camera is perfect for FPV drone racing, aerial surveillance, search and rescue operations, infrastructure inspection (power lines, buildings), wildlife monitoring, and any application requiring detailed thermal imaging from an aerial platform or embedded system.

Compatibility

The HTDRONE Mini2 camera supports multiple video output formats including Analog (PAL/NTSC), and Digital (DVP/BT656/USB2.0/MIPI). It features communication interfaces like UART, I2C, and USB2.0. Powered by 5V, it has a low typical power consumption of less than 0.7W via USB. Its compact dimensions and lightweight design facilitate integration into various drone frames and electronic systems.

FAQ

What is the HTDRONE Mini2 640x512 thermal camera used for?

The HTDRONE Mini2 640x512 is designed for FPV drones, industrial inspections, and monitoring. Its high-resolution thermal imaging capabilities make it ideal for detecting temperature differences in aerial applications, surveillance, and detailed inspections.

What are the key technical specifications of the HTDRONE Mini2 camera?

This camera features a 640x512 resolution, a 12 μm pixel size, and a 25 mK NETD for high sensitivity. It offers a 30/60 Hz refresh rate, multiple video outputs (Analog/Digital), and operates within a wide temperature range of -40°C to +80°C.

Is the HTDRONE Mini2 camera lightweight and suitable for FPV drones?

Yes, the HTDRONE Mini2 is extremely lightweight, weighing less than 8.6g without the lens, and has compact dimensions of 21x21x10.3 mm. This makes it perfectly optimized for integration into FPV drones without significantly impacting flight performance.

What video output formats does the HTDRONE Mini2 camera support?

The camera supports both analog video outputs (PAL/NTSC) and various digital video outputs including DVP, BT656, USB2.0, and MIPI, ensuring broad compatibility with different FPV systems and recording devices.
