IFlight Chimera7 Pro V2 O4 Pro BNF ELRS 868/915MHz Nano GPS Long Range FPV Drone

Introduction

The iFlight Chimera7 Pro V2 represents the king of FPV long-range flight. Equipped with the brand-new DJI O4 Air Unit, this 7.5-inch drone delivers an exceptional perspective and significantly increased flight range. It's designed for pilots who want to push boundaries, explore remote locations, and carry larger batteries for extended flight durations, making it ideal for adventurous endeavors like alpine FPV surfing. The Chimera7 Pro V2 offers a super-rigid frame for minimal resonance and powerful XING2 2809 motors, ensuring maximum control over its 7.5-inch propellers. You can mount larger batteries either on the top or bottom for optimal balance and flight time.

Key advantages

• Powerful XING2 Motors: Experience smooth and powerful flight with the latest generation of iFlight's XING motors, featuring a durable unibell design, titanium alloy shaft, and N52H magnets for ultimate performance and longevity.
• Advanced Chimera7 Pro Frame: The redesigned frame offers maximum protection against dirt and debris, preventing damage to your flight controller and ESCs. Strategic airflow keeps components cool without compromising performance.
• DJI O4 Video Transmission: Immerse yourself in flights with enhanced stability and extended range up to 13km. The O4 system provides low latency (24ms), high-definition 1080p/100fps video quality, and a maximum bitrate of 60 Mbps.
• 155° Ultra-Wide Angle 4K Video: Capture stunning, immersive aerial footage with the integrated camera's 155° field of view and 4K video recording capabilities.
• Protective XT60 Connector: Features a secured battery plug with an anti-spark filter to protect XT60 connectors and sensitive electronics from voltage and current spikes during battery connection.
• Integrated Nano GPS: Enhance safety with built-in GPS for easy Return-to-Home functionality and Betaflight GPS Rescue mode configuration.
• Extended Flight Time: Designed to carry larger batteries (e.g., 8000 mAh 6S), offering up to 30 minutes of hover time (unloaded), perfect for long-range exploration.
• 868/915MHz ELRS Receiver: Comes equipped with an iFlight ELRS receiver for reliable, long-range control link.

Technical specifications

• Product Name: Chimera7 Pro V2 6S HD
• Geometry: DC (DeadCat)
• Flight Controller: BLITZ F722
• ESC: BLITZ E55 4-IN-1 2-6S 55A
• Video Transmission: DJI O4 Air Unit Pro
• Frame Wheelbase: 327±2 mm
• Motor: XING2 2809 1250KV Motors
• Propellers: HQ 7.5x3.7x3 / HQ 7.5x3x3
• Weight: 725±5 g
• Takeoff Weight (with 8000mAh battery): Approx. 1621±5 g
• Dimensions: 270x199x34±2 mm
• Max Speed: 140 km/h
• Max Takeoff Altitude: 3200 m
• Max Hover Time: Approx. 30 min (unloaded with 21700 6S 8000 mAh)
• Operating Temperature: -10° to 40° C
• Antennas: Dual Antennas
• GNSS: GPS+SBAS+Galileo+QZSS+Glonass
• Receiver: iFlight ELRS 868/915 MHz RX
• Video Transmission - Product Name: DJI O4 Air Unit Pro
• Video Transmission - Image Sensor: 1/1.3 inch
• Video Transmission - Lens FOV: 155°
• Video Transmission - ISO: 100-25600
• Video Transmission - Video Resolution: 1080p/100fps H.265
• Video Transmission - Video Format: MP4
• Video Transmission - Max Video Bitrate: 130 Mbps
• Video Transmission - Color Mode: Normal Mode / D-Log M
• Video Transmission - Stabilization: RockSteady 3.0+ (can be disabled)
• Video Transmission - Live View Quality: 1080P@100fps
• Video Transmission - Operating Frequency: 5.170-5.250 GHz & 5.725-5.850 GHz
• Video Transmission - Transmitter Power (EIRP): 5.1 GHz＜23 dBm (CE)/5.8 GHz＜33 dBm (FCC)/＜14 dBm (CE)/＜30 dBm (SRRC)
• Video Transmission - Max Video Transmission Range: 15 km (FCC) with DJI Goggles 3/N3
• Video Transmission - Communication Bandwidth: Max 60 MHz
• Video Transmission - Built-in Storage: 4 GB
• Video Transmission - Supported SD Cards: microSD (up to 512 GB)
• Video Transmission - Weight: Air Unit (with Camera Module): Approx. 32 g

Applications

This FPV drone is ideal for long-range exploration, cinematic FPV flights, adventure videography, scenic flights, and pushing the limits of FPV flight distance. Its robust build and advanced features also make it suitable for high-performance FPV flying where reliability and range are paramount.

Compatibility

Compatible with DJI Goggles 3 and DJI Goggles N3. Supports 6S LiPo batteries (2-6S ESC). Uses HQ 7.5-inch propellers. Comes with an 868/915MHz ELRS receiver.

FAQ

What is the maximum flight range of the iFlight Chimera7 Pro V2 drone?

The iFlight Chimera7 Pro V2 drone features the DJI O4 Air Unit, which offers a maximum video transmission range of up to 15 km (FCC) with compatible goggles. This enables extended remote FPV flying experiences.

How long can the iFlight Chimera7 Pro V2 hover on a single charge?

With a large 8000 mAh 6S battery, the iFlight Chimera7 Pro V2 can achieve approximately 30 minutes of hover time when unloaded. This extended duration is ideal for long-range exploration missions.

Does the iFlight Chimera7 Pro V2 come with a GPS module for safety?

Yes, the iFlight Chimera7 Pro V2 includes a built-in Nano GPS module. This supports Return-to-Home functionality and can be configured with Betaflight GPS Rescue mode for added safety during long-distance flights.

Where can I buy the iFlight Chimera7 Pro V2 drone with reliable delivery?

You can buy the iFlight Chimera7 Pro V2 drone at HTDRONE. We offer fast shipping within Poland and reliable worldwide delivery via DHL, ensuring you receive your FPV equipment promptly.

What makes the Chimera7 Pro V2 suitable for long-range FPV flights?

The drone is designed for long range with its 7.5-inch propeller size, powerful XING2 motors, efficient frame, and the advanced DJI O4 Air Unit for superior video transmission and control link. It also supports larger batteries for extended flight times.
