IFlight Mach R5 Sport Analog 6S PNP FPV Racing Drone

Introduction

The iFlight Mach R5 Sport Analog 6S PNP is a high-performance FPV racing drone engineered for speed and agility. Designed for pilots who demand precision and reliability, this 5-inch drone offers a lightweight yet robust build, making it ideal for competitive racing and dynamic FPV experiences. Its compact design and advanced features ensure a superior flight experience.

Key Advantages

• Lightweight and Compact: Weighing just 302g, this 5-inch FPV drone features a redesigned frame layout for maximum space utilization and overall compactness.
• Innovative Quick-Release Aero Shell: The unique canopy is aerodynamically designed and includes a quick-release buckle for easy, one-turn replacement and maintenance. It also protects electronics from dirt and moisture.
• Convenient Operation: Features a secured battery plug to prevent propeller strikes, an integrated antenna for protection and aesthetics, and a front-mounted receiver socket for simplified replacement.
• Customizable DIY Space: Offers standard 20x20 mounting holes compatible with HDZERO and other VTXs, with adjustable antenna mounts and an optional carbon TPU canopy.
• High-Performance Components: Equipped with BLITZ Mini F722 Flight Controller, BLITZ E55R 4-in-1 ESC, BLITZ Force VTX 600mW, RaceCam Micro 1200TVL camera, and R5 2207 2050KV motors.
• Impressive Speed and Flight Time: Capable of reaching speeds up to 208 km/h with a maximum hover time of approximately 12 minutes (with 6S 1400mAh battery, no load).
• Durable Construction: Built with a 210mm wheelbase frame and designed to withstand challenging conditions, including wind speeds up to Level 6.

Technical Specifications

• Product Name: Mach R5 Sport 6S Analog
• Flight Controller: BLITZ Mini F722 Flight Controller
• ESC: BLITZ E55R 4-IN-1 2-6S 55A ESC
• Video Transmission: BLITZ Force VTX 600mW
• Camera: RaceCam Micro 1200TVL
• Frame Wheelbase: 210 mm
• Motor: R5 2207 2050KV Motors
• Propeller: Nazgul R5 V2 Propellers
• Weight: Approx. 295 g (without battery)
• Dimensions (L×W): 148*148*51 mm
• Max Speed: 208 km/h
• Max Takeoff Altitude: 6000 m
• Max Hover Time: Approx. 12 minutes (with 6S 1400mAh, no load)
• Max Wind Resistance: Level 6
• Operating Temperature: -10° to 40° C (14° to 104° F)
• Antennas: Single antenna
• GNSS: Not Applicable
• Receiver Option: No RX (PNP)
• Video Transmitter Output Power: 0-25-200-400-600mW
• Video Transmitter Input Voltage: 5V
• Video Transmitter Current Draw: ≤pit @80mA, ≤25mw@280mA, ≤100mw@405mA, ≤400mw@485mA, ≤600mw@575mA
• Video Transmitter Frequency: 40CH (A-B-E-F-R)
• Video Transmitter Antenna Interface: MMCX
• Video Transmitter Mounting Hole: 20x20 / Φ3mm / 25x25 / Φ2mm
• Video Transmitter Weight: 4g (W/O antenna)
• Video Transmitter Dimensions: 29x29mm

Applications

This FPV drone is primarily designed for FPV racing and freestyle flying. Its robust construction and high-speed capabilities also make it suitable for advanced hobbyists seeking thrilling aerial experiences. It can be used in various weather conditions due to its wind resistance and protective canopy.

Compatibility

The Mach R5 Sport features standard 20x20 mounting holes, ensuring compatibility with HDZERO and other VTX systems. The receiver socket is front-mounted for easy access. The drone is designed for 6S LiPo batteries.

FAQ

What makes the iFlight Mach R5 Sport Analog 6S PNP ideal for FPV racing?

The Mach R5 Sport Analog 6S PNP is built for racing due to its lightweight design (302g), compact 5-inch frame, and high-speed capabilities (up to 208 km/h). Its aerodynamic shell and robust components ensure performance and durability during intense races.

How easy is it to maintain the iFlight Mach R5 Sport Analog drone?

Maintenance is simplified with the innovative Quick-Release Aero Shell, allowing for easy replacement and access with just one turn of a buckle. The front-mounted receiver socket also streamlines component swaps.

What are the key technical specifications of the Mach R5 Sport 6S?

Key specs include a 210mm wheelbase, R5 2207 2050KV motors, BLITZ Mini F722 FC, BLITZ E55R ESC, and RaceCam Micro 1200TVL camera. It supports 6S batteries and offers a maximum hover time of around 12 minutes.

Can I use this drone with HDZERO or other VTX systems?

Yes, the Mach R5 Sport features standard 20x20 mounting holes, making it compatible with HDZERO and other VTX systems. It also offers customizable mounting options for antennas.

Where can I buy the iFlight Mach R5 Sport Analog 6S PNP drone with reliable delivery?

You can buy the iFlight Mach R5 Sport Analog 6S PNP drone directly from HTDRONE. We offer fast and reliable worldwide shipping via DHL, ensuring your order reaches you promptly.
