IFlight Nazgul DC5 ECO V1.1 O4 Pro BNF ELRS 2.4GHz + GPS FPV Drone

Introduction

The iFlight Nazgul DC5 ECO V1.1 O4 Pro is a cutting-edge 5-inch freestyle FPV drone designed to redefine performance and value in the FPV market. It's engineered for pilots who demand exceptional video quality, robust construction, and reliable flight performance. This drone is ideal for capturing breathtaking aerial footage and engaging in dynamic freestyle maneuvers, offering a premium experience without compromise. Get the best FPV drone deal at HTDRONE!

Key advantages

• Lightweight yet durable construction combining carbon fiber and aluminum for the camera equipment.
• Designed for unobstructed, propeller-free views, enhancing the aesthetic quality of aerial shots.
• Features an integrated protection circuit to prevent high current surges and protect XT60 connectors and electronics.
• Enhanced DJI O4 video transmission stability offers immersive flight experience and improved safety, with up to 13 km range and low latency.
• Equipped with a powerful BLITZ ATF435 Flight Controller and BLITZ E55S ESC for reliable and consistent performance.
• Captures stunning, stabilized 4K video even in low-light conditions with its 1/1.3-inch sensor.
• Includes a GoPro mount for versatile recording options.
• ELRS 2.4GHz receiver ensures a strong and stable control link.

Technical specifications

• Product Name: Nazgul DC5 ECO 6S O4 HD
• Geometry: DC (DeadCat)
• Flight Controller: BLITZ ATF435 Flight Controller
• ESC: BLITZ E55S 4-in-1 ESC
• Video Transmitter: DJI O4 Air Unit Pro
• Wheelbase: 240 mm
• Motors: XING-E Pro 2207 1800 KV
• Propellers: Nazgul F5
• Weight: 450 g ± 5 g
• Takeoff Weight: Approx. 675 g ± 5 g (with 6S 1480mAh battery)
• Dimensions (L×W×H): 193 × 144 × 34 mm
• Max. Speed: 190 km/h
• Max. Flight Altitude: 7000 m
• Max. Hover Time: Approx. 7.5 min (no load, with 6S 1480mAh battery)
• Wind Resistance: Level 7
• Operating Temperature: -10°C to 40°C (14°F to 104°F)
• Antennas: Dual
• GNSS: GPS + SBAS + Galileo + QZSS + Glonass (optional)
• Video Transmitter Product Name: DJI O4 Air Unit Pro
• Image Sensor: 1/1.3 inch
• Lens: FOV 155°
• ISO: 100-25600
• Video Resolution: 1080p/100fps H.265
• Video Format: MP4; Max. bitrate 130 Mbps
• Color Mode: Normal / D-Log M
• Stabilization: RockSteady 3.0+ (Standard Angle Only)
• Preview Quality: 1080p@100fps
• Frequency: 5.170-5.250 GHz & 5.725-5.850 GHz
• Transmitter Power (EIRP): 5.1 GHz < 23 dBm (CE) / 5.8 GHz < 33 dBm (FCC) / < 14 dBm (CE) / < 30 dBm (SRRC)
• Transmission Range: With DJI Goggles 3/N3: 15 km (FCC), 8 km (CE), 8 km (SRRC)
• Bandwidth: Max 60 MHz
• Antenna: Dual
• Storage: 4 GB
• Supported SD Cards: microSD up to 512 GB
• Temperature Range: -10°C to 40°C
• Air Unit Weight (with camera): Approx. 32 g
• Transmitter Module Dimensions: 33.5 × 33.5 × 13 mm

Applications

This FPV drone is primarily designed for freestyle piloting, aerial videography, and cinematic FPV flying. Its robust build and high-quality camera system make it suitable for capturing professional-looking footage in various environments. It can also be used for recreational flying and exploring the capabilities of advanced FPV technology. The optional GPS module enhances its capabilities for longer-range flights and potential navigation assistance.

Compatibility

The drone is compatible with DJI O4 Air Unit Pro video transmission systems and requires compatible FPV goggles (e.g., DJI Goggles 3). It utilizes ELRS 2.4GHz for control, requiring a compatible ELRS transmitter. It is designed to work with 6S LiPo batteries (1480 mAh recommended for optimal performance). The included GoPro mount allows for easy integration of action cameras.

FAQ

What is the iFlight Nazgul DC5 ECO V1.1 O4 Pro best suited for?

The iFlight Nazgul DC5 ECO V1.1 O4 Pro is best suited for freestyle FPV piloting and cinematic aerial videography. Its robust design, high-quality camera, and advanced video transmission system allow for dynamic maneuvers and stunning, stabilized 4K footage.

What is the video transmission system on this FPV drone?

This drone features the DJI O4 Air Unit Pro system, offering high-definition video transmission with a range of up to 13 km (depending on conditions and goggles). It provides a clear, low-latency 1080p/100fps feed for an immersive flying experience.

Does the iFlight Nazgul DC5 ECO V1.1 O4 Pro come with GPS?

Yes, the iFlight Nazgul DC5 ECO V1.1 O4 Pro is equipped with GPS + SBAS + Galileo + QZSS + Glonass (optional) for enhanced navigation capabilities and flight stability, especially beneficial for long-range flights or recording.

What are the key advantages of the Nazgul DC5 ECO V1.1 O4 Pro's frame construction?

The frame combines lightweight carbon fiber with an aluminum camera mount, ensuring durability while keeping the weight down. It's specifically designed to provide an unobstructed view, eliminating propeller wash in the video feed for cleaner aerial shots.
