IFlight iH3 O3 3.5" H-Frame FPV Drone Frame Kit - 168mm Wheelbase

Introduction

Discover the iFlight iH3 O3 3.5" Frame Kit, a meticulously engineered solution for FPV drone builders seeking performance and durability. This frame is designed with an H-shaped geometry, offering a balanced and stable platform ideal for a wide range of FPV applications. Whether you're assembling a freestyle rig or a cinematic cruiser, the iH3 O3 provides the foundation for a superior flying experience. Get yours at HTDRONE, your trusted source for FPV parts.

Key Advantages

• Robust H-shaped geometry for balanced flight characteristics.
• Generous 168mm wheelbase suitable for 3.5-inch propellers.
• Durable construction with 3mm thick arms and bottom plate for crash resistance.
• Optimized component mounting with flexible stack and VTX height options.
• Includes essential accessories like a TPU kit and anti-slip battery mat.
• Lightweight design at only 110 grams to maximize flight time and agility.
• Versatile motor mounting options (9x9mm/12x12mm).
• Ample space for modern VTX and stack configurations.

Technical Specifications

• Product Name: iH3 O3 3.5" Frame Kit
• Geometry: H-shape
• Wheelbase: 168 mm
• Frame Dimensions (L×W×H): 135 × 100 × 40 mm (from canopy)
• Arm Thickness: 3 mm
• Bottom Plate Thickness: 3 mm
• Top Plate Thickness: 2 mm
• Max Stack Height: 19 mm
• Max VTX Height: 22 mm
• Motor Mount: 9x9mm/12x12mm
• VTX Mount: 20*20 Φ2 mm / 25.5*25.5 Φ1.6 mm
• Weight: 110 grams

Applications

This frame is ideally suited for building custom FPV drones for freestyle flying, cinematic aerial videography, and general FPV hobbyist use. Its robust design and versatile mounting options make it a great choice for pilots looking to experiment with different setups and component combinations for their 3.5-inch builds.

Compatibility

The iFlight iH3 O3 frame supports motor mounting patterns of 9x9mm and 12x12mm. It offers flexible VTX mounting options for 20x20mm and 25.5x25.5mm standards, accommodating various digital and analog VTX units. The maximum stack height is 19mm, and the maximum VTX height is 22mm, ensuring compatibility with most popular flight controllers and electronic speed controllers.

FAQ

What is the iFlight iH3 O3 frame best suited for?

The iFlight iH3 O3 frame is best suited for building custom 3.5-inch FPV drones. Its H-shaped geometry and robust construction make it ideal for freestyle flying and cinematic FPV applications where stability and durability are key.

What are the key dimensions of the iFlight iH3 O3 frame?

The frame features a 168mm wheelbase. Its dimensions are 135mm long, 100mm wide, and 40mm high (from the canopy). The arms and bottom plate are 3mm thick, with a 2mm top plate.

What motor and VTX mounting options does the iH3 O3 frame offer?

This frame supports motor mounting patterns of both 9x9mm and 12x12mm. For VTX mounting, it accommodates 20x20mm (Φ2mm) and 25.5x25.5mm (Φ1.6mm) standards, providing flexibility for various electronic setups.

Where can I buy the iFlight iH3 O3 frame with reliable delivery?

You can buy the iFlight iH3 O3 frame at HTDRONE. We are based in Poland and offer worldwide shipping via DHL for fast and reliable international delivery. Check our store for the best deals.

What is included in the iFlight iH3 O3 frame kit?

The kit includes the iH3 frame, a screw bag, a TPU kit for mounting accessories, an anti-slip battery mat, and a battery strap. This provides a comprehensive package for starting your drone build.
