IFlight Commando 8 Pro 868MHz/2.4GHz 1W Dual-Band Radio Controller for FPV

Introduction

The iFlight Commando 8 Pro is a cutting-edge dual-band radio controller designed for the demanding FPV and UAV pilot. It offers unparalleled control and versatility, featuring simultaneous operation on both 2.4GHz and 868/915MHz frequencies. This advanced transmitter solves the common problems of signal loss and interference, especially in complex environments and during long-range flights, providing a robust and reliable connection for your drone.

Key advantages

• Dual-Band, Dual-Antenna Power: Equipped with two LR1121 RF chips and dual antennas, it operates simultaneously on 2.4GHz and 868/915MHz bands, each delivering 1W of power for superior range and signal integrity.
• Enhanced Interference Resistance: Utilizes three transmission modes (Gemini, True Diversity, Gemini Xrossband) for excellent noise immunity and exceptional flight control reception quality.
• Multi-Packet Redundancy: The DK500 mode transmits identical data packets on two different frequencies concurrently, drastically improving connection reliability.
• Extended Battery Life: Enjoy up to 3 hours of flight at 1W or around 6 hours at 100mW. Features a 6400mAh battery and supports 20W PD fast charging for a full charge in just 80 minutes.
• Versatile Simulator Compatibility: Supports both Type-C wired connection and Bluetooth, making it compatible with popular FPV simulators like Liftoff, Velocidrone, DRL, and Uncrashed for effective training.
• OpenTX/EdgeTX Support: Fully controllable with 2x 5-axis menu buttons for comprehensive OpenTX or EdgeTX operation.
• High RF Output: Delivers a powerful 1W (30 dBm) RF output on all supported frequencies.
• TCXO Crystal Oscillator: Ensures stable frequency performance with temperature compensation.

Technical specifications

• Band Options: Dual-Band
• Dual Antennas: 2.4 GHz + 868/915 MHz
• Button Functions: 2x 5-axis menu buttons, 2x 2-position switches (non-momentary), 2x 3-position switches
• MCU: STM32F407VET6
• RF Chip: Semtech LR1121
• Protocol: ELRS
• Frequency: 2.4 GHz / 868/915 MHz
• RF Power: ELRS 2.4 GHz/868/915 MHz 1W (30 dBm)
• Antenna: 2.4 GHz/868/915 MHz Dual-Band, Dual
• Charging: PD 20W Quick Charge
• Battery: Built-in 6400mAh (2x 1S2P 18650)
• Dimensions: 154 x 165 x 72 mm (±0.5)
• Weight: 315 g ± 10 g
• TCXO: Yes
• Firmware: iFlight ELRS Commando 8 GemX TX
• Lua Script: iF GemX C8 TX
• Compatibility: Compatible with TBS TX module

Applications

This controller is ideal for FPV drone racing, long-range exploration, UAV operations, aerial photography, and professional drone piloting. Its robust signal and versatility also make it excellent for simulator training.

Compatibility

Supports multiple RF protocols and packet modes including Gemini, True Diversity, and Gemini Xrossband. Compatible with FPV simulators via Type-C or Bluetooth. Also compatible with TBS TX modules.

FAQ

What is the iFlight Commando 8 Pro and who is it for?

The iFlight Commando 8 Pro is a high-performance dual-band radio controller designed for FPV enthusiasts and professional UAV pilots. It offers exceptional control and reliability for FPV racing, long-range flights, and complex aerial operations.

What are the key transmission features of the Commando 8 Pro?

It features dual-band operation (2.4GHz and 868/915MHz) with 1W output power per band, utilizing Gemini, True Diversity, and Gemini Xrossband modes for superior interference resistance and signal stability. It also supports Multi-Packet Redundancy for enhanced connection reliability.

How long does the battery last and how is it charged?

The built-in 6400mAh battery provides up to 3 hours of operation at 1W and around 6 hours at 100mW. It supports 20W PD fast charging, allowing a full charge in approximately 80 minutes.

Is the iFlight Commando 8 Pro compatible with FPV simulators?

Yes, it offers excellent compatibility with popular FPV simulators such as Liftoff, Velocidrone, DRL, and Uncrashed. It supports both Type-C wired connections and Bluetooth for seamless integration.

Where can I buy the iFlight Commando 8 Pro with reliable delivery?

You can buy the iFlight Commando 8 Pro at HTDRONE, our specialized FPV parts store. We offer fast shipping within Poland and reliable worldwide delivery via DHL, ensuring you receive your order promptly.
