Pilotix 5330 320KV Brushless Motor for Heavy-Duty FPV Drones

Introduction

The Pilotix 5330 320KV motor is a high-performance brushless powerhouse designed for substantial FPV drones and heavy-lift applications. It excels where unwavering reliability and stable operation are paramount. Its sturdy construction and finely tuned specifications ensure superior performance, even under the most challenging operational conditions. This motor is the perfect choice for professional-grade drones, industrial tasks, and bespoke, large-scale aerial platforms.

Key Advantages

• Exceptional Power Output: Delivers up to 4090.79W for demanding flight maneuvers.
• High Thrust Capability: Generates a maximum thrust of 11025g, suitable for heavy payloads.
• Optimized for 12S Batteries: Engineered to efficiently utilize 12S power systems.
• Durable Construction: Built with robust materials for longevity in tough environments.
• Precise Control: Offers stable and reliable performance for critical applications.
• Efficient Operation: Designed for optimal power efficiency and heat management.
• Ideal for Large Drones: Specifically suited for larger FPV and UAV platforms.

Technical Specifications

• KV: 320 kv
• Internal Resistance: 25 mΩ
• Battery Support: 12S
• Shaft Diameter: 6mm
• Maximum Thrust: 11025g
• Maximum Power: 4090.79W
• Stator Poles: 12N14P
• Dimensions: φ62.4 * 86.8 mm
• Silicone Wire: 14AWG, 750mm
• Weight (with wire): 653g
• Maximum Current: 96.39A
• No-load Current: 1.8A

Applications

This motor is ideally suited for a wide range of applications including professional FPV drones, heavy-lift UAVs, industrial inspection platforms, aerial photography and videography with large camera setups, and custom large-scale drone builds requiring significant power and stability.

Compatibility

Designed for 12S battery systems. Features a 6mm shaft diameter suitable for various propellers. Includes a 750mm 14AWG silicone wire for flexible installation.

FAQ

What is the Pilotix 5330 320KV motor best suited for?

The Pilotix 5330 320KV motor is best suited for large FPV drones and heavy-duty applications that require high power, efficiency, and reliable performance. It is ideal for professional UAVs and custom large-scale models.

What battery voltage does the Pilotix 5330 320KV motor support?

This motor is designed to work with 12S battery systems, offering substantial power for demanding flights and heavy payloads.

What are the key technical specifications of the Pilotix 5330 320KV motor?

Key specifications include 320KV, 25 mΩ internal resistance, a 6mm shaft diameter, 11025g maximum thrust, and 4090.79W maximum power. It supports 12S batteries and weighs 653g with the wire.

Where can I buy the Pilotix 5330 320KV motor with fast delivery?

You can buy the Pilotix 5330 320KV motor at HTDRONE. We offer fast international delivery via DHL, ensuring you receive your high-performance FPV parts quickly.

What kind of applications can benefit from the Pilotix 5330 320KV motor?

Applications include professional FPV drones, industrial inspection UAVs, heavy-lift platforms for aerial photography, and custom large-scale drone builds demanding robust power delivery.
