Pilotix 6215 210KV Brushless Motor for Heavy-Lift FPV & UAV Drones

Introduction

The Pilotix 6215 210KV is a powerful and reliable brushless motor specifically designed for large multirotor platforms and high-power demanding applications. It ensures smooth, stable operation and consistent torque, making it ideal for professional film platforms, industrial drones, mapping platforms, and long-range carriers. Its optimized design delivers high performance under heavy loads, while a solid stator and bearing system ensures long-lasting durability. Whether for professional aerial work or demanding custom builds, the 6215 210KV offers dependable power and exceptional thrust.

Key advantages

• High-performance stator and winding design for smooth and efficient operation.
• Significant lift capacity suitable for professional heavy-lift drones and high-endurance UAVs.
• Durable construction with low internal resistance for enhanced reliability.
• Optimized for stable operation with large propellers and high-current ESC systems.
• Extended motor leads for easier installation on larger frames.
• Provides reliable power and exceptional thrust for heavy-duty applications.
• Engineered for professional aerial platforms and custom drone builds.

Technical specifications

• Motor Model: 6215-210KV
• Kv (Speed Constant): 210Kv
• Inter-phase Resistance: 42.5 mΩ
• Shaft Diameter: 6 mm
• Weight (with wire): 409 g
• Maximum Power: 2182.2 W
• Maximum Thrust: 7898 g (at 8S)
• Pole Configuration: 24N / 28P
• Motor Size: 68.8 x 41 mm (diameter x length)
• Motor Wire: 14AWG, 670 mm length
• No-load Current (at 7.4V): 0.9 A
• Maximum Current: 65.51 A
• Motor Mounting Pattern: 4 M4 holes, 25 mm diameter
• Propeller Mount: 8 M3 holes, fits D = 12-18 mm

Applications

This motor is perfectly suited for professional aerial platforms, heavy-lift FPV drones, industrial UAVs, long-range mapping drones, cinematic production drones, and demanding custom drone builds requiring significant power and thrust.

Compatibility

• Recommended Propeller: 2055-2
• Recommended ESC: HW-HV260A (V5)
• Recommended Power Supply: ACPOWER-60V-133A
• Mounting Pattern: 4 M4 holes, 25 mm diameter
• Propeller Mount: 8 M3 holes, fits D = 12-18 mm

FAQ

What is the Pilotix 6215 210KV motor best suited for?

The Pilotix 6215 210KV motor is best suited for large multirotor platforms, professional film platforms, industrial drones, mapping drones, and long-range carriers that require high power and significant thrust for heavy payloads.

What are the key technical specifications of the Pilotix 6215 210KV motor?

This motor features a 210Kv speed constant, 6mm shaft diameter, and weighs 409g. It offers a maximum power of 2182.2W and a maximum thrust of 7898g (at 8S), with a 24N/28P pole configuration.

What propeller size is recommended for the Pilotix 6215 210KV motor?

The recommended propeller for the Pilotix 6215 210KV motor is the 2055-2. This size is optimized to work with the motor's power output for efficient flight.

What ESC and power supply are recommended for this motor?

For optimal performance, a HW-HV260A (V5) ESC and an ACPOWER-60V-133A power supply are recommended to ensure stable and efficient operation with the Pilotix 6215 210KV motor.

Where can I buy the Pilotix 6215 210KV motor with reliable delivery?

You can buy the Pilotix 6215 210KV motor at HTDRONE. We offer fast shipping within Poland and reliable worldwide delivery via DHL for international customers.
