Pilotix Brook 2.5-inch Cinewhoop 4S Analog FPV Drone ELRS 2.4G for Cinematic Flights

Introduction

The Pilotix Brook 2.5-inch Cinewhoop is a highly maneuverable FPV drone designed specifically for professional aerial cinematography in confined and complex environments. This compact powerhouse combines agility with stability, making it the ultimate tool for capturing smooth, dynamic footage where larger drones cannot operate. Whether you're filming indoors, navigating tight urban landscapes, or exploring challenging indoor structures, the Brook Cinewhoop offers an unparalleled flight experience and exceptional video quality.

Key Advantages

• Compact Cinewhoop Design: Integrated propeller guards allow for safe operation in close-quarters and sensitive environments.
• Powerful 4S System: High-performance brushless motors and a 4S power setup deliver responsive control and ample flight duration.
• Precision Flight Control: An optimized flight controller with advanced tuning ensures stable, precise handling for smooth cinematic shots.
• Durable and Lightweight: Constructed with a robust yet lightweight frame for maximum agility and resilience.
• Versatile Application: Perfect for indoor filming, complex environment navigation, and capturing dynamic FPV footage.
• Ready for ELRS: Equipped with an ELRS 2.4G receiver for reliable, long-range control.
• High-Quality Components: Features a reliable F7 40A AIO FC, Pilotix-1405 4800KV motors, and a quality FPV camera system.
• Easy Documentation Access: Get technical details easily via our support link.

Technical Specifications

• Product Name: Brook 2.5"
• Frame: Brook 2.5"
• Flight Controller (FC): F7 40A AIO
• Motor: Pilotix-1405 4800KV
• Propeller: HQProp DT63-3
• Video Transmitter (VTX): 5.8G 1.3W
• FPV Camera: Ratel 2
• Antenna: Cherry Angle MMCX RHCP
• Receiver: ELRS 2.4G
• System Voltage: 4S
• Analog System: Yes

Applications

This FPV drone is ideally suited for professional FPV cinematography, indoor aerial filming, real estate videography, event coverage in confined spaces, and any application requiring stable, smooth footage in tight environments. Its cinewhoop design makes it perfect for getting close to subjects or navigating complex structures safely.

Compatibility

The Pilotix Brook 2.5-inch Cinewhoop comes equipped with an ELRS 2.4G receiver, ensuring compatibility with ExpressLRS radio transmitters. It operates on a 4S LiPo battery system, requiring a compatible battery and charger. The analog FPV system is compatible with standard 5.8GHz FPV goggles.

FAQ

What is the Pilotix Brook 2.5-inch Cinewhoop drone best suited for?

The Pilotix Brook 2.5-inch Cinewhoop is specifically designed for smooth, cinematic FPV flights in tight and complex spaces. Its compact size and integrated propeller guards make it ideal for indoor filming, navigating challenging environments, and capturing stable footage near subjects.

What are the key technical specifications of the Pilotix Brook 2.5" drone?

This drone features a 2.5-inch frame, an F7 40A AIO flight controller, Pilotix-1405 4800KV motors, HQProp DT63-3 propellers, a 5.8G 1.3W VTX, Ratel 2 FPV camera, and an ELRS 2.4G receiver, all powered by a 4S system.

Does the Pilotix Brook 2.5" cinewhoop come with a receiver?

Yes, the Pilotix Brook 2.5-inch Cinewhoop comes equipped with an ELRS 2.4G receiver, ensuring reliable and responsive control with compatible ExpressLRS transmitters.

Where can I buy the Pilotix Brook 2.5-inch Cinewhoop FPV drone?

You can buy the Pilotix Brook 2.5-inch Cinewhoop FPV drone at HTDRONE, your specialized FPV parts store. We offer fast and reliable delivery within Poland and worldwide shipping via DHL.

Is this Pilotix drone suitable for beginners?

The Pilotix Brook 2.5-inch Cinewhoop offers precise handling and stability, making it suitable for both experienced pilots and beginners looking to get into cinematic FPV flying. Its forgiving flight characteristics and durable design help ease the learning curve.
