Pilotix BLS 6in1 65A ESC 3-6S for FPV Drones

Introduction

The Pilotix BLS 6in1 ESC is a high-performance electronic speed controller designed for the most demanding FPV applications. It ensures reliable and robust power delivery, essential for executing rapid maneuvers and maintaining stable flight. This ESC is the ideal choice for both professional pilots and dedicated enthusiasts looking to enhance their FPV experience with superior control and durability.

Key Advantages

• High continuous current rating of 65A per motor, with a burst capability of 75A.
• Wide input voltage range supporting 3-6S LiPo batteries (10.5-25.2V).
• Advanced BLheli_S 16.7 / Bluejay 0.19.2 firmware for precise throttle response.
• Supports multiple ESC protocols including DShot150/300/600, MultiShot, and OneShot.
• Durable construction with a 6-layer, 3OZ copper PCB for efficient heat dissipation.
• Onboard capacitors (35V 1000uf*1, 35V 470uf*3) for stable power delivery.
• Integrated current sensing for real-time monitoring.
• Bidirectional DShot support for advanced telemetry.

Technical Specifications

• Model Name: Pilotix BLS 65A 6IN1 ESC
• Input Voltage: 3-6S (10.5-25.2V)
• Operating Temperature: -40℃ to 80℃
• Continuous Current (per motor): 65A
• Burst Current (per motor): 75A
• Continuous Power (per motor): 1600W
• Peak Power (per motor): 1900W
• Current Sensor: Yes
• Telemetry: No
• Bidirectional DShot: Support
• ESC Firmware: BLheli_S 16.7 / Bluejay 0.19.2
• ESC Protocol: DShot150/300/600/MultiShot/ OneShot PWM etc.
• Dimensions (L*W/H): 93x77x29mm
• Onboard Capacitors: 35V 1000uf*1, 35V 470uf*3
• Connector: Amass MR30
• PCB: 6-layer 3OZ copper
• Configurator Tool: https://esc-configurator.com/

Applications

This ESC is perfectly suited for high-performance FPV racing drones, freestyle quadcopters, and other demanding UAV applications that require precise power control and high current handling. Ideal for builds utilizing 5-inch to larger propeller sizes.

Compatibility

Compatible with 3-6S LiPo batteries. Supports various ESC protocols including DShot, MultiShot, and OneShot. Features an Amass MR30 connector. Requires adequate heat dissipation and an active cooling fan when operating under sustained high current.

FAQ

What is the Pilotix BLS 6in1 ESC and who is it for?

The Pilotix BLS 6in1 ESC is a high-performance electronic speed controller designed for demanding FPV applications. It is ideal for professional pilots and enthusiasts seeking reliable power delivery and precise throttle control for their FPV drones.

What is the maximum current rating for the Pilotix BLS 6in1 ESC?

This ESC provides a continuous current of 65A per motor, with a burst current capability of up to 75A per motor. It supports input voltages from 3S to 6S LiPo batteries.

What ESC protocols and firmware does the Pilotix BLS 6in1 ESC support?

The Pilotix BLS 6in1 ESC runs on BLheli_S 16.7 or Bluejay 0.19.2 firmware and supports various protocols like DShot150/300/600, MultiShot, OneShot, and PWM.

How should I ensure proper cooling for this ESC?

When operating at consistently high currents, it is strongly recommended to ensure adequate heat dissipation. Utilizing an active cooling fan is highly advised to maintain optimal performance and longevity.
