Pilotix Ground Station PCB 20km Transmission Range, Fiber Optic Data Link

Introduction

The Pilotix Ground Station PCB is a core component designed for advanced unmanned systems, including drones, underwater ROVs, and ground robotics. It provides a high-performance data link solution utilizing single-mode fiber optics, ensuring reliable communication even when radio links fail. This module is specifically for users who need maximum flexibility in integrating a powerful communication system into custom builds, as it comes without a casing or wires.

Key Advantages

• Extended 20km transmission range for long-distance operations.
• Stable, high-speed, and interference-free data transmission via single-mode fiber.
• Ideal for applications requiring low latency and high security.
• Enables communication in environments where radio is unreliable.
• Bare PCB design offers maximum flexibility for custom integration.
• Supports bidirectional data flow for comprehensive control and telemetry.
• Compatible with NTSC/PAL/SECAM video formats.
• Offers TTL/SBUS data formats for broad system compatibility.

Technical Specifications

• Module Type: Fiber Optic Module
• Device Name: Ground Unit 20 km
• Fiber Interface: FC Interface
• Fiber Type: Single-mode Fiber
• Data Interface: SH1.0
• Video Format: NTSC/PAL/SECAM
• Data Direction: Bidirectional
• Data Format: TTL/SBUS
• Speed: 0~1Mbps
• Single-mode Wavelength: 1550 (9/125μm)
• Transmission Range: Single-mode Fiber up to 20 km

Applications

This Pilotix ground station PCB is designed for a wide range of demanding applications. It is perfect for long-range FPV systems, professional UAV operations requiring stable telemetry and control, robotic ground vehicles, and underwater ROVs. Its robust fiber optic link makes it suitable for industrial inspections, surveillance, and any scenario where reliable, secure, and low-latency data transmission is critical.

Compatibility

Pilotix fiber optic communication modules are designed for exclusive compatibility within the same series. To ensure reliable performance, it is crucial to use this module with transmitters and receivers from the same Pilotix series. Compatibility with devices from other series is not guaranteed, and HTDRONE is not responsible for operational issues arising from mixed-series usage.

FAQ

What is the maximum reliable transmission range for the Pilotix Ground Station PCB?

For reliable communication up to 9 km, a 20 km range receiver is recommended. For distances between 10 km and 14 km, a 40 km range receiver is advised. For transmissions exceeding 15 km up to 20 km and beyond, a 60 km range receiver is recommended.

What type of fiber optic cable does this Pilotix ground station module use?

This Pilotix ground station PCB utilizes single-mode fiber optic cable, specifically operating at a wavelength of 1550nm (9/125μm), for its extended 20 km transmission range.

Is this Pilotix ground station PCB compatible with other brands or series?

No, Pilotix fiber optic communication modules are exclusively compatible with devices from the same series. Using modules from different series is not guaranteed to work and is not supported by HTDRONE.

Who is the target audience for the Pilotix Ground Station PCB?

This bare PCB module is ideal for developers, system integrators, and advanced hobbyists who require maximum flexibility in mounting and integrating a high-performance, long-range communication system into custom-built drones, ROVs, or robotic platforms.

Where can I buy the Pilotix Ground Station PCB with fast delivery?

You can buy the Pilotix Ground Station PCB directly from HTDRONE. We offer fast shipping within Poland and reliable worldwide delivery via DHL for international orders.
