Pilotix PT-15 Lite 15-inch FPV Drone Frame for Heavy Lift Missions

Introduction

The Pilotix PT-15 Lite is a high-performance, heavy-duty frame designed for demanding FPV and UAV applications. It offers exceptional reliability and stability, making it the perfect choice for pilots who require a solid foundation for their long-range or heavy-lift drones. Its advanced carbon fiber design ensures that your drone can handle significant payloads while maintaining precise flight control.

Key Advantages

• High-reliability carbon fiber construction for durability.
• Reinforced design minimizes vibrations and resonance for stable flight.
• Optimized for 15-inch propellers, delivering powerful thrust.
• Exceptional rigidity and strength, crucial for long-range missions.
• Simple yet robust design for easy assembly and maintenance.
• Engineered for heavy payloads and high-speed applications.
• Ensures stable performance even under maximum load.

Technical Specifications

• Model: PT15 Lite
• Wheelbase: 610 mm
• Arm Thickness: 9 mm
• Top Plate Width: 46 mm
• Top Plate Length: 310 mm
• Top Plate Thickness: 3 mm
• Bottom Plate Width: 80 mm
• Bottom Plate Length: 150 mm
• Bottom Plate Thickness: 3 mm
• Compatible Propeller Size: 15 inches
• Overall Width: 460 mm
• Overall Length: 405 mm

Applications

This frame is ideally suited for a variety of applications including heavy-lift FPV drones, long-range exploration UAVs, aerial photography platforms requiring stability, and specialized industrial inspection missions where payload capacity and flight endurance are paramount.

Compatibility

The Pilotix PT-15 Lite frame is designed to accommodate standard FPV components suitable for 15-inch propeller setups. Its robust structure is compatible with high-power motors and large batteries required for extended flight times and heavy lifting.

FAQ

What are the main advantages of the Pilotix PT-15 Lite frame for FPV drones?

The Pilotix PT-15 Lite frame offers exceptional reliability due to its reinforced carbon fiber construction, which minimizes vibrations and resonance for stable flight. It's specifically designed for heavy lift missions and supports 15-inch propellers for high thrust.

What is the recommended application for the Pilotix PT-15 Lite frame?

This frame is best suited for heavy-lift FPV drones, long-range exploration UAVs, and aerial platforms that need to carry significant payloads. Its robust design ensures stability and performance under demanding conditions.

What are the key technical specifications of the Pilotix PT-15 Lite frame?

The frame features a 610mm wheelbase, 9mm thick arms, and robust 3mm thick top and bottom plates. It is compatible with 15-inch propellers, offering a width of 460mm and a length of 405mm.

Where can I buy the Pilotix PT-15 Lite frame with reliable delivery?

You can buy the Pilotix PT-15 Lite frame at HTDRONE. We offer fast and reliable international delivery via DHL from our base in Poland.

Is the Pilotix PT-15 Lite frame suitable for beginners?

While the PT-15 Lite is designed for demanding applications, its straightforward yet strong construction can be manageable for experienced builders. Its rigidity and stability are excellent for advanced long-range builds.
