Pilotix PT8 ELRS 4.9-5.8G Ratel PRO 2.5W FPV Drone for Long Range Flights

Introduction

The Pilotix PT8 ELRS 4.9-5.8G Ratel PRO 2.5W is a top-tier 8-inch FPV drone designed for pilots demanding long-range capabilities and superior video transmission. Combining premium components with advanced technology, this FPV quadcopter delivers an unparalleled flying experience. It's engineered for comfort and clarity, making it a perfect choice for extended aerial missions.

Key advantages

• High-performance 8-inch FPV drone for extended range flights.
• Integrated ELRS 868/915MHz receiver for reliable control.
• Powerful 4.9-5.8G 2.5W VTX ensures a strong and clear video signal.
• Caddx Ratel Pro camera delivers crisp, high-quality FPV video feed.
• Robust Partizan PT8 frame with 6mm thick arms for durability.
• Advanced F405 V2 FC with Betaflight 4.4.3 firmware for precise control.
• Capable of carrying payloads up to 2500g, with impressive flight times.
• High maximum speed of 150 km/h and altitude of 6000m MSL.

Technical specifications

• Model: PT8 PRO ELRS 4.9-5.8G 2.5W
• Frame: Partizan PT8 new version
• Dimensions: 317x270x50mm
• Weight: 700g
• Wheelbase: 358mm
• Arm Thickness: 6mm
• Bottom/Top Plate Thickness: 2mm
• FC: F405 V2 ICM42688P with additional module
• Firmware: Betaflight 4.4.3
• ESC: 60A (burst 70A)
• VTX: 4.9-5.8G 2.5W
• VTX Antenna: Long 5.8G RHCP SMA
• Motor: 2812-900KV/1300KV
• Propeller: GEMFAN 8060-3
• Camera: Caddx Ratel Pro
• Gimbal system: None
• Receiver: ELRS 915Mhz Diversity Rx Cyclone
• GPS: None
• Recommended Battery: 6S 8000Mah Lipo
• Flight time with 8000mAh battery: 35 minutes (no load), 16 minutes (2.5kg load), 22 minutes (2kg load)
• Maximum Speed: 150 km/h
• Maximum Flight Altitude (MSL): 6000 m
• Maximum Ascent Speed: 15 m/s
• Stable Operating Temperature Range: -20 ℃ - 50 ℃
• Payload Capacity: 2000-2500g

Applications

This FPV drone is ideal for long-range exploration, aerial photography with payloads, demanding FPV racing, and professional UAV operations requiring stable flight and clear video feedback. Its robust build and high-power VTX make it suitable for challenging environments.

Compatibility

The Pilotix PT8 is recommended for use with a 6S 8000mAh Lipo battery. It features an ELRS 915MHz receiver for control and a 5.8GHz FPV video transmission system. The Caddx Ratel Pro camera ensures excellent video quality.

FAQ

What is the maximum flight time of the Pilotix PT8 ELRS drone?

With a recommended 6S 8000mAh Lipo battery, the Pilotix PT8 ELRS drone can achieve up to 35 minutes of flight time without any payload. With a 2kg payload, expect around 22 minutes, and with a 2.5kg payload, approximately 16 minutes.

What FPV camera does the Pilotix PT8 ELRS drone use?

The Pilotix PT8 ELRS drone is equipped with the high-quality Caddx Ratel Pro camera, known for delivering a clear and sharp video image, essential for precise FPV flying.

What is the VTX power and range of the Pilotix PT8 ELRS drone?

This drone features a powerful 4.9-5.8G 2.5W VTX, ensuring a strong and stable video signal over long distances, enhancing your FPV experience.

Where can I buy the Pilotix PT8 ELRS FPV drone with reliable delivery?

You can buy the Pilotix PT8 ELRS FPV drone at HTDRONE. We offer fast shipping within Poland and reliable worldwide delivery via DHL for international customers. Check our store for the best price and availability.

What are the key specifications of the Pilotix PT8 ELRS 2.5W drone?

Key specs include an 8-inch frame, ELRS 915MHz receiver, 2.5W VTX, Caddx Ratel Pro camera, F405 V2 FC with Betaflight 4.4.3, and a 60A ESC. It boasts a 358mm wheelbase and supports payloads up to 2500g.
