Pilotix Rocky 13" SV ELRS 868/915MHz Long Range FPV Drone

Pilotix Rocky 13" SV ELRS 915MHz: Your Ultimate Long-Range FPV Drone

The Pilotix Rocky 13" SV is a formidable 13-inch FPV quadcopter engineered for heavy payloads and extended flight times. Equipped with an advanced ELRS 868/915MHz Diversity receiver, it guarantees a stable and reliable connection, even at extreme distances. This drone is specifically constructed to meet the challenges of professional aerial photography, detailed inspections, and other demanding applications, providing unparalleled stability and performance. Its rugged build and sophisticated features make the Pilotix Rocky 13" SV the premier choice for operators requiring a potent and trustworthy FPV quadcopter for critical operations.

Key Advantages

• Extended Range Capability: Utilizes ELRS 868/915MHz Diversity for superior signal reliability over long distances.
• Heavy-Lift Performance: Designed for substantial payloads, capable of carrying up to 6000g.
• Professional Aerial Photography: Offers stable flight characteristics ideal for high-quality aerial imaging.
• Durable Construction: Built with a robust Pilotix 13" x-class frame for resilience in demanding conditions.
• Long Flight Times: Achieves up to 35 minutes of flight with dual 6S 8000mAh batteries (unloaded).
• High-Speed Potential: Capable of reaching a maximum speed of 140 km/h.
• Advanced Flight Controller: Features the Pilotix F405 with ICM42688P gyro and Betaflight 4.4.3 firmware for precise control.
• Customizable Build: Comes without VTX, antenna, camera, or battery, allowing for personalized component selection.

Technical Specifications

• Model: 13" Simple Version
• Frame: Pilotix 13" x-class frame
• Dimensions: 480x470x100mm
• Weight: Approximately 2000g
• Wheelbase: 590mm
• Arm Tube Diameter: 25mm
• Bottom/Top Plate Thickness: 2mm
• Flight Controller (FC): Pilotix F405 ICM42688P gyro
• Firmware: Betaflight 4.4.3
• Electronic Speed Controller (ESC): Pilotix BLS 100A single ESC
• Video Transmitter (VTX): None
• VTX Antenna: None
• Motor: 4312 660KV
• Propeller: GEMFAN 1310-3 *4
• Receiver: ELRS 915Mhz Diversity RX
• Camera: None
• Gimbal System: None
• Landing Gear: None
• GPS: None
• Positioning System: None
• Recommended Battery: 6S 8000mAh Lipo *2
• Flight Time (with 2x 8000mAh battery): 35 min (no load), 18 min (4kg load), 10 min (6kg load)
• Max Speed: 140 km/h
• Max Flight Altitude (MSL): 7000 m
• Max Ascent Speed: 20 m/s
• Stable Operating Temperature: -20 ℃ to 50 ℃ (-4 °F to 122 °F)
• Maximum Payload: 6000g

Applications

The Pilotix Rocky 13" SV is ideal for long-range FPV flights, professional aerial photography, heavy-lift drone operations, industrial inspections, and advanced UAV applications requiring extended flight times and reliable long-distance control.

Compatibility

This drone is compatible with 6S 8000mAh Lipo batteries (two recommended). It requires separate purchase of VTX, antenna, camera, and batteries. The ELRS 915MHz Diversity RX ensures broad compatibility with ELRS radio systems.

Documentation: Inquire about documentation

Package Contents: 1x Pilotix Rocky 13" SV ELRS915 FPV Drone

FAQ

What is the maximum payload capacity of the Pilotix Rocky 13" SV drone?

The Pilotix Rocky 13" SV drone is designed for heavy-lift operations and can carry a maximum payload of up to 6000g. This makes it suitable for demanding tasks requiring significant carrying capacity.

What is the expected flight time for the Pilotix Rocky 13" SV drone?

With the recommended dual 6S 8000mAh Lipo batteries, the Pilotix Rocky 13" SV drone offers impressive flight times: up to 35 minutes without any payload, 18 minutes with a 4kg load, and 10 minutes with a 6kg load.

Does the Pilotix Rocky 13" SV drone come with a camera and VTX?

No, this version of the Pilotix Rocky 13" SV drone does not include a VTX, antenna, camera, or battery. These components must be purchased separately to complete your build.

What makes the ELRS 868/915MHz Diversity receiver beneficial for this drone?

The ELRS 868/915MHz Diversity receiver ensures a highly reliable and stable long-range connection. Diversity means it uses multiple antennas to optimize signal reception, crucial for maintaining control over extended distances.
