Pilotix Rocky13 Advanced ELRS 5.8G 3W Long Range FPV Drone

Introduction

The Pilotix Rocky13 Advanced is a formidable 13-inch FPV quadcopter designed for heavy-duty operations and extended range flights. Engineered for reliability and performance, this drone is your go-to solution for professional aerial photography, surveillance, and other demanding UAV tasks. Its advanced features and robust construction ensure stable flight and superior control, even in challenging conditions. Shop the Pilotix Rocky13 Advanced at HTDRONE for a premium FPV experience.

Key Advantages

• Exceptional Long Range: Equipped with ELRS 868/915Mhz Diversity receiver for stable, long-distance control.
• Powerful Video Transmission: Features a 5.8G 3W VTX for clear, uninterrupted FPV video feeds.
• Heavy-Lift Capability: Designed to carry payloads up to 6000-8000g, perfect for professional use.
• Durable Construction: Built with a sturdy Pilotix 13" X-Class Frame and 2mm thick carbon plates for resilience.
• High Performance: Powered by Pilotix 4218 540kv motors and Pilotix 80A ESCs for maximum efficiency.
• Advanced Flight Control: Utilizes Pilotix F405 V3 FC with Betaflight/INAV firmware support.
• Integrated GPS: Includes an M10 GPS module for precise positioning and navigation.
• Extended Flight Times: Offers up to 35 minutes of flight time without payload (with dual 6S 8000mAh batteries).

Technical Specifications

• Model: Rocky13 Advanced
• Frame: Pilotix 13" X-Class Frame
• Dimensions: 480x470x100mm
• Weight: 2000g
• Wheelbase: 590mm
• Arm Tube Diameter: 25mm
• Bottom/Top Plate Thickness: 2mm
• Flight Controller (FC): Pilotix F405 V3 Gyro
• Firmware: Betaflight/INAV
• Electronic Speed Controller (ESC): 4x Pilotix 80A burst 90A single ESC with heatsink
• Video Transmitter (VTX): Pilotix 5.8G 3W
• Antenna: Rush Cherry II 5.8G RP-SMA RHCP, 160mm
• Motor: Pilotix 4218 540kv (6S)
• Propellers: GEMFAN 1310-3
• Camera: Caddx Ratel PRO 1500tvl + SERVO
• Landing Gear: Not included
• Receiver: ELRS Diversity with 2x T-antennas 915Mhz
• Positioning System: M10 GPS BZ251
• Recommended Battery: 2x 6S 8000mAh Lipo (not included)
• Flight Time (2x 8000mAh): 35 min (no load), 18 min (4kg load), 10 min (6kg load)
• Max Speed: 160 km/h
• Max Altitude (MSL): 7000m
• Max Ascent Speed: 20 m/s
• Stable Operating Temperature: -20°C to 50°C (-4°F to 122°F)
• Payload Capacity: 6000-8000g

Applications

This FPV drone is ideal for professional aerial photography, cinematic videography, long-range exploration, surveillance, inspection tasks, and heavy payload delivery missions. Its robust design makes it suitable for commercial and industrial applications requiring a reliable and powerful UAV platform.

Compatibility

The Pilotix Rocky13 Advanced is designed for use with 2x 6S 8000mAh Lipo batteries, which must be ordered separately. It supports Betaflight and INAV firmware, offering flexibility for different flight control preferences.

FAQ

What is the Pilotix Rocky13 Advanced FPV drone best suited for?

The Pilotix Rocky13 Advanced is best suited for professional applications like heavy-lift operations, long-range FPV flights, aerial photography, and cinematic videography due to its robust 13-inch frame and powerful components.

What is the maximum flight time of the Pilotix Rocky13 Advanced?

With dual 6S 8000mAh Lipo batteries (sold separately), the drone can achieve up to 35 minutes of flight time without any payload. With a 4kg payload, expect around 18 minutes, and with a 6kg payload, approximately 10 minutes.

Does the Pilotix Rocky13 Advanced come with a battery?

No, the battery is not included with the Pilotix Rocky13 Advanced. It requires two 6S 8000mAh Lipo batteries, which need to be purchased separately. Check our selection for compatible batteries.

Where can I buy the Pilotix Rocky13 Advanced FPV drone with reliable delivery?

You can buy the Pilotix Rocky13 Advanced FPV drone at HTDRONE. We offer fast and reliable shipping options, including worldwide delivery via DHL, ensuring you receive your order promptly.

What type of radio control system does the Pilotix Rocky13 Advanced use?

This advanced model features an ELRS (ExpressLRS) Diversity receiver operating on 868/915Mhz frequencies, providing a highly reliable and long-range radio control link for your FPV flights.
