Pilotix Single ESC 12S 100A for FPV Drones and Multicopters

Introduction

The Pilotix 12S 100A ESC is a high-performance and reliable electronic speed controller designed for demanding FPV drones and large multicopters. Built upon the advanced AM32 firmware and featuring an AT32F421 microcontroller, this ESC delivers exceptionally smooth throttle response, accurate current measurement, and stable operation, especially in high-voltage configurations. It's the ideal component for serious FPV enthusiasts and professional UAV operators looking to maximize their aircraft's potential.

Key Advantages

• Supports advanced protocols including bidirectional DShot for precise RPM filtering.
• Integrated current sensor and telemetry for real-time monitoring of critical flight data.
• Compact and lightweight design with a standard mounting pattern for easy integration.
• Optimized for 6-12S LiPo batteries, making it suitable for large-scale FPV and UAV applications.
• Leverages the powerful AT32F421 MCU for superior processing and control.
• AM32 firmware ensures smooth performance and advanced features.
• Built-in ammeter for detailed current analysis during flight.
• Reliable and durable construction for demanding aerial operations.

Technical Specifications

• Rated Current: 100A
• Peak Current: 120A
• MCU: AT32F421G8U7
• Input Signal: PWM, Bidirectional Dshot300/600
• Telemetry: Supported
• Input Voltage: 6-12S LiPo
• Firmware: AM32
• Built-in Ammeter: Supported
• Mounting Hole: M3 30.5 x 30.5 mm
• Weight: 19 g

Applications

This ESC is perfectly suited for a wide range of applications including high-performance FPV racing drones, freestyle FPV rigs, large-scale aerial photography platforms, professional inspection UAVs, and any custom multirotor build requiring robust power delivery and precise control up to 12S. Check the best deals for your next build!

Compatibility

The Pilotix 12S 100A ESC is compatible with standard FPV flight controllers supporting PWM and DShot (including bidirectional DShot). It is designed for LiPo batteries ranging from 6S to 12S. The standard 30.5x30.5mm mounting pattern ensures compatibility with most FPV and drone frames. Order yours today for reliable performance!

FAQ

What is the Pilotix Single ESC 12S 100A best suited for?

The Pilotix Single ESC 12S 100A is ideal for high-performance FPV drones and large multicopters that require robust power delivery and precise control. Its advanced features make it suitable for FPV racing, freestyle, and professional aerial applications using 6-12S LiPo batteries.

What firmware does the Pilotix 12S 100A ESC use?

This ESC utilizes the advanced AM32 firmware, known for its smooth throttle response and efficient performance. It's powered by an AT32F421 microcontroller, ensuring reliable operation and support for features like bidirectional DShot.

What input voltage does the Pilotix 100A ESC support?

The Pilotix 100A ESC supports a wide input voltage range of 6-12S LiPo batteries, making it versatile for various large-scale drone builds and power requirements.

Can I get telemetry data from this Pilotix ESC?

Yes, the Pilotix 12S 100A ESC supports telemetry data, including current sensing. This allows for real-time monitoring of critical parameters during flight, enhancing safety and performance analysis.

Where can I buy the Pilotix ESC 12S 100A with fast delivery?

You can buy the Pilotix ESC 12S 100A directly from HTDRONE. We are based in Poland and offer fast shipping within Poland and reliable worldwide delivery via DHL. Check our store for the best deals and order yours today!
