RadioMaster TX15 ExpressLRS White FPV RC Radio Controller with Hall Gimbals

Introduction

The RadioMaster TX15 ExpressLRS White is a versatile and compact radio controller engineered for contemporary FPV and RC pilots who demand reliability and flexibility. Equipped with the powerful ExpressLRS protocol, it delivers ultra-low latency and robust long-distance performance. The TX15 boasts an ergonomic design, a crisp color touchscreen display, smooth gimbals, and a customizable interface, making it comfortable and intuitive to use even during extended sessions. With support for multiple model profiles, open-source firmware, and external module compatibility, it's future-proof and ready to adapt to your flying style. Perfect for both novice and professional pilots looking for a high-performance radio link in an elegant, portable form factor. Buy the best FPV transmitter at HTDRONE.

Key Advantages

• Ultra-Fast Performance: Powered by an STM32 H7 chipset for exceptionally responsive control.
• Vibrant Touchscreen: Features a 3.5-inch IPS touchscreen (480x320 resolution) with vivid colors and sharp details.
• Precise Gimbals: Equipped with V5.0 Hall sensor gimbals for smooth and accurate control inputs.
• Integrated ExpressLRS: Built-in 2.4 GHz / Sub-G 868/915 MHz ExpressLRS ensures reliable long-range control.
• Efficient Cooling System: High-performance quiet fans and an aluminum heatsink keep the radio cool during intensive use.
• Foldable Antenna: Compact and easy to store without compromising signal strength.
• Built-in Gyroscope: Enables advanced features like tilt-to-steer or control via radio tilting.
• Expandable Storage: Integrated 4GB flash memory with MicroSD card support for custom configurations and logging.

Technical Specifications

• Product: TX15 Radio Controller
• Dimensions: 178 x 168 x 81 mm
• Weight: 605 g (without battery)
• Frequency: 2.400 GHz OR Sub-G 868/915 MHz
• Internal RF: ELRS 2.4 GHz / Sub-G 868/915 MHz
• Supported Protocols: Express-LRS
• Cooling Fan: Yes
• Transmitter Module: Built-in ELRS
• Internal Flash Memory: 4 GB
• Built-in Microphone: Yes (future expandable)
• Built-in Gyroscope: Yes (ICM-42607-C)
• MicroSD Card Support: Up to 32 GB/FAT32 (Note: Inserting microSD disables internal flash)
• Antenna Gain: 2 dB (Adjustable transmit power)
• Current Draw: 875 mA at maximum output power
• Voltage Range: 6.6-8.4 V DC
• Radio Firmware: EdgeTX
• Module Firmware: ExpressLRS
• Channels: Max 16 channels (receiver dependent)
• Display: 3.5-inch IPS Touchscreen (480 x 320 resolution)
• Battery Compatibility: 2-cell 7.4V LiPo, two 3.7V 18650 Li-Ion, or 21700 5000 mAh battery (batteries not included)
• Connectivity: USB-C
• Gimbals: V5.0 Hall Sensor Gimbals (Standard)
• Gimbal Sticks: M4
• Update Method: USB-C (UF2)
• Module Bay: JR module bay compatible
• Color: White

Applications

This high-performance radio controller is ideal for a wide range of applications including FPV racing, freestyle flying, long-range exploration, drone cinematography, UAV operations, and general RC model control. Its advanced features and reliable connectivity make it suitable for demanding aerial tasks.

Compatibility

The RadioMaster TX15 is compatible with ExpressLRS receivers operating on 2.4 GHz or Sub-G frequencies. It features a standard JR module bay for expanding compatibility with external RF modules. The USB-C port allows for firmware updates and configuration using EdgeTX and ExpressLRS software. It supports various battery types including 7.4V LiPo, 3.7V 18650 Li-Ion, and 21700 batteries (not included).

FAQ

What makes the RadioMaster TX15 ExpressLRS White ideal for FPV pilots?

The RadioMaster TX15 ExpressLRS White is ideal for FPV pilots due to its integrated ExpressLRS module, offering ultra-low latency and reliable long-range control. Its Hall sensor gimbals provide precise inputs, and the ergonomic design ensures comfort during long flights. It's a top choice for competitive racing and freestyle.

Can I use the RadioMaster TX15 with different types of receivers?

Yes, the TX15 primarily uses the ExpressLRS protocol, supporting both 2.4 GHz and Sub-G (868/915 MHz) frequencies. Ensure your receiver is compatible with ExpressLRS for optimal performance. It also features a JR module bay for additional external RF modules.

What are the advantages of the Hall sensor gimbals on the TX15?

The V5.0 Hall sensor gimbals offer superior precision, durability, and smoothness compared to traditional gimbals. They are less prone to wear and tear and provide a more consistent feel, which is crucial for accurate control in FPV and RC applications.

What kind of batteries can I use with the RadioMaster TX15?

The RadioMaster TX15 is compatible with a 2-cell 7.4V LiPo battery, two 3.7V 18650 Li-Ion batteries using the included tray, or a single 21700 5000 mAh battery. Please note that batteries are not included with the controller.

Where can I buy the RadioMaster TX15 ExpressLRS White with fast delivery?

You can buy the RadioMaster TX15 ExpressLRS White at HTDRONE. We offer fast and reliable international delivery via DHL, ensuring you receive your order promptly. Check our shop for the best deals and pricing.
