GEPRC GEP-GR1507 3600KV FPV Drone Motor for 3-4 inch Builds

Introduction

The GEPRC GEP-GR1507 motor is specifically designed to elevate the performance of 3-inch and 4-inch FPV and UAV drone platforms. It addresses the need for improved power delivery, efficiency, and durability, making it an excellent choice for drone enthusiasts and racers looking for a competitive edge. With multiple KV options and advanced features, this motor ensures a smoother, more powerful flight experience.

Key advantages

• Precision CNC machining with 7075 aluminum alloy for superior strength and durability.
• High-performance N52H arc magnets deliver excellent torque and high-temperature resistance.
• Optimized power output curve, providing the best thrust between 50% and 90% throttle.
• Dynamically balanced motor body minimizes vibrations and noise at high speeds for a cleaner flight.
• Smooth operation guaranteed by high-quality Japanese NSK bearings.
• Enhanced power delivery thanks to plate-shaped magnets and a narrow 0.15mm air gap.
• Innovative heat dissipation structure reduces motor temperature by up to 20% compared to similar motors.
• Lightweight design at only 15.5g for improved drone agility and flight time.

Technical specifications

• Item Name: GEP-GR1507
• KV Option: 3600KV
• Configuration: 12N14P
• Stator Diameter: 15 mm
• Stator Length: 7 mm
• Shaft Diameter: 2 mm (hollow)
• Motor Dimensions (Dia x L): 19.6mm x 29.1mm
• Battery (LiPo): 2-4S
• Rotor: N52H arc magnets
• Bearings: NSK
• Base casing: Al 7075
• Wire Gauge: 24AWG
• Weight: 15.5g

Applications

This motor is ideal for building and upgrading 3-inch and 4-inch FPV racing drones, freestyle quadcopters, and compact aerial photography platforms. Its robust design and high KV rating make it suitable for agile flight maneuvers and competitive racing.

Compatibility

The GEPRC GEP-GR1507 motor is compatible with 2-4S LiPo batteries. Its standard 2mm hollow shaft and 19.6mm diameter make it compatible with most FPV frames designed for 3-4 inch builds. Ensure your ESCs are rated appropriately for the motor's power output.

FAQ

What is the best application for the GEPRC GEP-GR1507 3600KV motor?

The GEPRC GEP-GR1507 3600KV motor is best suited for 3-inch and 4-inch FPV drone builds, particularly for FPV racing and freestyle flying where high performance and agility are crucial.

What are the key technical advantages of the GEP-GR1507 motor?

Key advantages include its precision CNC machined 7075 aluminum construction, high-torque N52H magnets, Japanese NSK bearings for smooth operation, and an optimized heat dissipation structure that reduces temperature by up to 20%.

What LiPo battery voltage is recommended for the GEPRC GEP-GR1507 motor?

This motor is designed to work with 2-4S LiPo batteries, offering flexibility depending on your desired power output and flight characteristics for your FPV drone.

How does the GEPRC GEP-GR1507 motor improve efficiency?

It features plate-shaped magnets and a narrow 0.15mm air gap to increase power delivery efficiency. The design is optimized for excellent thrust delivery between 50% and 90% throttle.

Where can I buy the GEPRC GEP-GR1507 3600KV motor with fast delivery?

You can buy the GEPRC GEP-GR1507 3600KV motor at HTDRONE. We offer fast shipping within Poland and reliable worldwide delivery via DHL. Check our store for the best price and deals.
