GEPRC SPEEDX2 2105.5 3450KV Titanium Brushless Motor for FPV Drones

Introduction

Discover the next generation of FPV drone propulsion with the GEPRC SPEEDX2 2105.5 brushless motor. Engineered for peak performance, this motor combines cutting-edge design with robust materials to deliver unparalleled speed and reliability for your FPV quadcopter. Whether you're into freestyle, racing, or long-range exploration, the SPEEDX2 2105.5 is built to exceed expectations.

Key Advantages

• Exceptional Lightweight Design: Weighing only 21.0 grams, it minimizes overall drone weight for improved agility and flight time.
• Advanced Heat Dissipation: The innovative flat construction significantly enhances cooling efficiency, maintaining lower operating temperatures for sustained performance.
• Versatile Propeller Compatibility: Features a 1.5mm shaft diameter, perfectly matching most conventional 3-5 inch FPV propellers on the market.
• High KV Rating: With a 3450KV rating, it provides aggressive power delivery for high-speed maneuvers and quick throttle response.
• Durable Titanium Finish: The striking titanium color not only looks great but also signifies the quality and durability of the motor's construction.
• Optimized for 3-4S LiPo: Designed to work seamlessly with 3-4S LiPo batteries, offering a wide operational range.
• Robust Construction: Built with N52H ARC magnets and a 12N14P configuration for reliable and powerful operation.
• Superior Power Output: Delivers a maximum continuous power of 558W and a peak current of 34.9A for demanding flights.

Technical Specifications

• Model: SPEEDX2 2105.5-3450KV
• KV: 3450KV
• Configuration: 12N14P
• Magnets: N52H ARC
• Stator Diameter: 21 mm
• Stator Height: 5.5 mm
• Shaft Diameter: 3.0 mm (inner), 1.5 mm (outer)
• Overall Size: 25.65 mm x 15.7 mm
• Motor Wires: 22#AWG 150mm
• LiPo Cell Count: 3-4S
• Max Continuous Power: 558 W
• Max Current: 34.9 A
• Mounting Holes: 12 mm x 12 mm (M2 screw)
• Color: Titanium
• Weight: 21.0 g

Applications

This GEPRC SPEEDX2 2105.5 motor is perfectly suited for a variety of FPV applications, including agile 3-4 inch FPV whoops, lightweight 4-5 inch Toothpick-style drones, and long-range FPV aircraft. Experience enhanced flight dynamics and responsiveness across different FPV disciplines.

Compatibility

The motor features standard M2 mounting holes with a 12mm x 12mm pattern, compatible with most FPV frames. Its 1.5mm outer shaft diameter ensures broad compatibility with a wide range of 3-5 inch FPV propellers. Designed for 3-4S LiPo batteries, it offers flexibility for various power setups.

FAQ

What is the main advantage of the GEPRC SPEEDX2 2105.5 motor?

The main advantage is its exceptional lightweight design, weighing only 21.0 grams, combined with advanced flat construction for superior heat dissipation, ensuring sustained high performance during demanding FPV flights.

What size FPV drones is the GEPRC SPEEDX2 2105.5 motor best suited for?

This motor is ideal for 3-4 inch FPV whoops, 4-5 inch Toothpick-style drones, and long-range FPV builds. Its 1.5mm shaft is compatible with most 3-5 inch FPV propellers.

What LiPo battery voltage is recommended for the GEPRC SPEEDX2 2105.5 motor?

The motor is designed to work with 3-4S LiPo batteries, offering a versatile power range for various FPV setups. It can handle up to 558W of continuous power.

How does the flat design benefit the GEPRC SPEEDX2 2105.5 motor?

The flat design significantly improves heat dissipation, helping to maintain lower operating temperatures. This prevents overheating and ensures consistent performance, even during extended flight sessions.

Where can I buy the GEPRC SPEEDX2 2105.5 3450KV Titanium motor with fast delivery?

You can buy the GEPRC SPEEDX2 2105.5 3450KV Titanium motor at HTDRONE. We offer fast shipping within Poland and reliable worldwide delivery via DHL, ensuring you get your parts quickly.
