Sub250 Huma20 O3 FPV Drone Frame - Lightweight, Durable, DJI O3 Ready

Introduction

The Sub250 Huma20 O3 frame is a cutting-edge FPV drone component designed for pilots seeking high-definition aerial experiences. This frame provides a perfect balance of lightweight construction and robust durability, making it an ideal platform for both dynamic freestyle maneuvers and smooth cinematic footage. Its design is specifically optimized for seamless integration with the DJI O3 Air Unit, ensuring you get the best possible video quality.

Key advantages

• Lightweight Design: Engineered for superior agility and flight responsiveness.
• Durable Construction: Built to withstand rigorous flights and ensure longevity.
• DJI O3 Air Unit Optimized: Ensures high-definition video transmission quality.
• Compact Form Factor: Perfect for navigating tight spaces and performing intricate maneuvers.
• Vibration-Damping Camera Mount: Guarantees stable and clear video footage.
• Universal Electronics Layout: Compatible with a wide range of flight controllers and components.
• Efficient Power Distribution: Supports extended flight times for longer missions.

Technical specifications

• Model Name: Huma20
• Weight: Approx. 47±2 g
• Motor to Motor Distance: 95 mm
• Top Plate Thickness: 2.0 mm
• Bottom Plate Thickness: 2.0 mm
• Arm Thickness: 2.0 mm
• Equipment Layer Height: 22 mm
• VTX Mounting Hole Spacing: 20 x 20 mm / 25.5 x 25.5 mm
• Retaining Ring Hole Diameter: 4 mm
• Motor Mounting Holes: 9 x 9 mm
• Camera Mounting Spacing: 20 mm
• Recommended Battery: 650 mAh-750 mAh
• Recommended Motor: Sub250 1304 6000KV
• Flight Controller Mounting Holes: 25.5 mm

Applications

This frame is exceptionally suited for FPV freestyle flying, cinematic FPV, and high-definition drone videography. Its compact size and responsive handling make it a versatile choice for various aerial projects where clarity and maneuverability are paramount.

Compatibility

The Sub250 Huma20 O3 frame features universal electronics mounting, a VTX mounting hole spacing of 20x20mm and 25.5x25.5mm, and standard 20mm camera mounting. It's designed to accommodate flight controllers with 25.5mm mounting holes and is recommended for use with Sub250 1304 6000KV motors and 650-750mAh batteries.

FAQ

What is the Sub250 Huma20 O3 frame best suited for?

The Sub250 Huma20 O3 frame is ideal for FPV freestyle flying and cinematic applications, especially when paired with the DJI O3 Air Unit for high-definition video transmission. Its lightweight and compact design ensures excellent agility.

What are the key technical specifications of the Sub250 Huma20 O3 frame?

The frame features a 95mm motor-to-motor distance, 2.0mm thick plates and arms, and weighs approximately 47±2g. It supports 20x20mm and 25.5x25.5mm VTX mounting and 25.5mm flight controller mounting.

What components are recommended for the Sub250 Huma20 O3 frame?

For optimal performance, the Sub250 1304 6000KV motor and a 650-750mAh battery are recommended. The frame is designed to integrate seamlessly with the DJI O3 Air Unit.

Where can I buy the Sub250 Huma20 O3 FPV frame?

You can buy the Sub250 Huma20 O3 FPV frame at HTDRONE, your specialized FPV and UAV drone parts store based in Poland. We offer fast delivery within Poland and worldwide shipping via DHL.

Does the Sub250 Huma20 O3 frame come with all necessary mounting hardware?

Yes, the kit includes a comprehensive set of screws and mounting hardware, along with top and bottom plates, aluminum parts, battery straps, and a cable part for easy assembly.
