Sub250 OasisFly35 DC Analog FPV Drone ELRS 2.4GHz Freestyle

Introduction

The Sub250 OasisFly35 DC Analog FPV Drone is engineered for pilots who appreciate the traditional feel and clarity of analog FPV systems combined with contemporary drone construction. It delivers a pure analog video experience, enhanced by a robust power system and the reliability of ELRS 2.4GHz control, making it ideal for both experienced flyers and those transitioning to a more performance-oriented platform. This drone is designed to provide an immersive and dependable FPV experience from the moment you unbox it.

Key Advantages

• Pure analog FPV performance with a stable Sub250 Send T1600 VTX, Momoda MMCX antenna, and Caddx H1 camera.
• Clean DC frame design with front-tilt to eliminate propeller view obstruction for a clearer analog picture.
• Integrated mech-style side plates protect electronics, improve airflow, and enhance aerodynamics.
• CNC-machined aluminum camera mount provides maximum durability against impacts.
• High-thrust 1804 3450KV motors and a 45A AIO ESC deliver powerful acceleration and precise control.
• Included SUB-M10 GPS module for GPS rescue and enhanced flight safety.
• Versatile Multi-VTX readiness, supporting Analog, O3, and O4 Pro systems.
• Lightweight design: only 239g with a 4S 530mAh battery, offering up to 7 minutes of flight time and sub-250g compliance.
• Integrated ELRS 2.4GHz receiver ensures ultra-responsive control and stable long-range signal.

Technical Specifications

• Model: Oasisfly35 DC Analog Version
• Wheelbase: 175 mm
• Arm Thickness: 3.5 mm
• Bottom Plate: 1.5 mm
• Middle Plate: 2.5 mm
• Top Plate: 2.0 mm
• Motor Mount Pattern: 9x9 mm / 12x12 mm
• VTX: Sub250 Send T1600
• VTX Antenna: Momoda-MMCX90
• Camera: Caddx H1
• Motor: 1804 3450KV
• FC: Redfox A3 45A AIO
• ESC Firmware: BLHeli_32
• MCU: STM32F722
• IMU: ICM42688-P
• Propeller: HQ 3.5x3.5x3
• Receiver: ELRS 2.4 GHz
• GPS: SUB-M10
• Recommended Battery: 4S 530 mAh
• Power Connector: XT30
• Dry Weight: 188 g
• Takeoff Weight: 239 g
• Max Flight Time: 7 min
• FC Firmware: Betaflight_4.5.2-SUB250REDFOXF722AIO

Applications

This FPV drone is ideally suited for freestyle flying, offering a responsive and immersive experience. Its durable construction and included GPS make it suitable for practicing advanced maneuvers, exploring flight areas, and ensuring safer flights in complex environments. Pilots who prefer the classic analog video feed will find this drone a perfect match for dynamic aerial performance.

Compatibility

The Sub250 OasisFly35 DC Analog is designed for broad compatibility. It supports multiple VTX systems including Analog, DJI O3, and O4 Air Units, offering flexibility for future upgrades. The integrated ELRS 2.4GHz receiver ensures seamless connection with compatible radio transmitters. It uses a standard XT30 power connector for batteries and supports 4S 530mAh LiPo batteries for optimal performance and flight time.

FAQ

What is the Sub250 OasisFly35 DC Analog FPV Drone best suited for?

The Sub250 OasisFly35 DC Analog FPV Drone is best suited for freestyle FPV flying. Its design emphasizes a clean analog video feed, responsive ELRS 2.4GHz control, and durable construction, making it ideal for performing and practicing maneuvers.

Does the Sub250 OasisFly35 DC Analog FPV Drone come with GPS?

Yes, the Sub250 OasisFly35 DC Analog FPV Drone includes the SUB-M10 GPS module. This feature enables GPS rescue functionality, enhancing flight safety, especially in complex environments or during long-range flights.

What is the maximum flight time for the Sub250 OasisFly35 DC Analog FPV Drone?

With the recommended 4S 530mAh battery, the Sub250 OasisFly35 DC Analog FPV Drone has a maximum flight time of up to 7 minutes. Its lightweight design contributes to efficient power usage.

Can I use different FPV video transmission systems with this drone?

Yes, the Sub250 OasisFly35 DC Analog FPV Drone is ready for Multi-VTX systems, supporting Analog, DJI O3, and O4 Pro video transmitters. This provides flexibility for pilots who may wish to change their VTX setup in the future.

Where can I buy the Sub250 OasisFly35 DC Analog FPV Drone with reliable delivery?

You can buy the Sub250 OasisFly35 DC Analog FPV Drone at HTDRONE. We offer fast shipping within Poland and reliable worldwide delivery via DHL for international orders.
