Walksnail Avatar HD Pro Kit with Caddx GM2 Gimbal & Dual Antennas | 1080p H.265 | FPV Drone System

Introduction

The Gimbal + Avatar Pro Kit (Dual Antennas) is a professional FPV flight solution designed for pilots who demand exceptional image quality, minimal latency, and maximum signal stability. The Avatar HD system utilizes the advanced H.265 codec, delivering a fluid 1080p FPV experience with low latency and high detail. This kit is ideal for cinematic FPV pilots, racers, and anyone looking to capture high-quality aerial footage.

Key Advantages

• Stunning 1080p HD Video: Experience crystal-clear visuals with the 1/1.8" Sony Starvis Ⅱ camera sensor.
• Low Latency Transmission: Average latency of just 22ms ensures a responsive FPV connection.
• Enhanced Stability: Gyroflow support and the integrated Caddx GM2 gimbal provide exceptionally smooth footage.
• Superior Low-Light Performance: The Sony Starvis Ⅱ sensor delivers a clear and bright image, even in challenging night conditions.
• Dual Antenna Design: Improved 5.8 GHz signal stability, reduced signal drops, and increased interference resistance.
• Onboard 32GB Storage: Record 1080p or 720p footage directly without needing an external recorder.
• Wide Voltage Input: Compatible with a broad range of drone setups, supporting 6-25.2V.
• Robust Construction: Built for demanding FPV applications.

Technical Specifications

Camera

• Model: Avatar HD Pro Camera
• Sensor: 1/1.8" Sony Starvis Ⅱ
• Resolution: 1080P/60fps; 720P/120fps; 720P/60fps; 1080P/120fps compatibility
• Aspect Ratio: 16:9; 4:3
• Lens: 8Mp
• FOV: 160°
• Aperture: F1.6
• Shutter: Rolling shutter
• Min. Illumination: 0.00001 Lux
• Weight: 9.5 g
• Dimensions: 19 × 19 × 24 mm
• Coaxial Cable: 140 mm

VTX

• Model: Avatar V2 Pro Module (Dual Antenna)
• Band: 5.725-5.850 GHz
• Transmitter Power (EIRP): FCC <30 dBm; CE <14 dBm; SRRC <20 dBm; MIC <25 dBm
• Interface: JST1.0 (Power in), JST0.8 (USB)
• Mounting Holes: 25.5 × 25.5 mm; 20 × 20 mm
• Dimensions: 33.5 × 33.5 × 10.5 mm
• Memory: 32 GB
• Recording: 1080p / 720p
• Weight: 15.4 g
• Operating Temperature: -20 ~ 40°C
• Channels: 8
• Power Input: 6V-25.2V
• Supported FC: Betaflight; Inav; Fettec; ArduPilot; Kiss
• OSD: Canvas mode
• Latency: Average 22 ms
• Antenna: 2× IPEX

Avatar V2 Antenna

• Polarization: LHCP
• Frequency Range: 5600-6000 MHz
• Gain: 1.9 dBi
• VSWR: ≤ 1.5
• Impedance: 50 Ω
• Connector: IPEX-1
• Size: R15 × 45 mm (without cable)
• Weight: 2 g

Applications

This kit is perfect for FPV drones used in cinematic filming, competitive racing, freestyle acrobatics, and general aerial videography. Its advanced features also make it suitable for UAV applications requiring high-quality video transmission and recording.

Compatibility

The Avatar VTX module supports a wide input voltage range of 6V-25.2V, making it compatible with most FPV flight controllers and battery configurations. It features mounting holes for both 25.5x25.5mm and 20x20mm stacks. The system is compatible with popular flight controllers like Betaflight, Inav, Fettec, ArduPilot, and Kiss.

FAQ

What is the main advantage of the Walksnail Avatar HD Pro Kit?

The main advantage is its combination of a high-quality 1080p camera with a stabilized Caddx GM2 gimbal and a dual-antenna VTX for superior image clarity, minimal latency (average 22ms), and robust signal stability, enhanced further by Gyroflow support.

Who is the Walksnail Avatar HD Pro Kit best suited for?

This kit is ideal for FPV pilots focused on cinematic filming, freestyle, and demanding aerial videography where high-quality, stable footage is crucial. It's also suitable for professional UAV applications requiring reliable HD video transmission.

What resolution and recording capabilities does the Avatar HD Pro Kit offer?

The kit records in 1080p or 720p resolution. It features onboard 32GB storage, allowing you to capture footage directly without needing an external recording device, ensuring you don't miss critical moments.

What are the power requirements and compatibility of the VTX module?

The Avatar V2 Pro VTX module supports a wide input voltage range of 6V to 25.2V, making it compatible with various drone power systems. It also supports popular flight controllers like Betaflight, Inav, Fettec, ArduPilot, and Kiss.
