Walksnail Video Repeater 5.8G/5.2G for Walksnail Avatar HD System

Introduction

The Walksnail Video Repeater is an essential component for FPV enthusiasts using the Walksnail Avatar HD System. This advanced signal extension module is engineered to significantly enhance the stability and range of your video transmission, ensuring a clear and uninterrupted feed even in challenging environments. It's designed for pilots who demand the utmost reliability and performance from their FPV setups.

Key Advantages

• Extended signal range for improved FPV experiences.
• Dual-band 5.8G and 5.2G communication frequencies for versatile performance.
• Supports high-definition video transmission up to 1080p @ 100fps for crystal-clear imagery.
• Compatible with the Walksnail Avatar HD System, ensuring seamless integration.
• Robust design with multiple power input options (9V-26V).
• High gain antennas (7dBi) for superior signal reception and transmission.
• Compact and lightweight design for easy mounting on various drone builds.
• Provides reliable video links for long-range FPV, racing, and aerial cinematography.

Technical Specifications

• Communication Frequency: 5.15 GHz - 5.30 GHz & 5.50GHz - 5.85GHz
• Transmitter Power (EIRP): FCC: <30dBm, CE: <14dBm, SRRC: <20dBm, MIC: <25dBm
• 5.2G Antenna: Frequency Range: 5.15GHz - 5.30GHz, Gain: 7dBi (average), Polarization: LHCP
• 5.8G Antenna: Frequency Range: 5.50GHz - 6.00GHz, Gain: 7dBi (average), Polarization: LHCP
• System: Avatar HD System
• Power Input: 9V - 26V
• Dimensions: 119.5 mm x 72 mm x 18.6 mm
• Weight: 145g (antenna not included)
• Interfaces: USB Port, 4-pin 1.0mm pitch connector
• Transmission Resolution: 1080p @ 100fps, 1080p @ 60fps, 720p @ 100fps, 720p @ 60fps

Applications

This video repeater is perfect for FPV drone racing, freestyle flying, long-range exploration, aerial photography, and professional UAV operations where a stable and high-quality video link is critical. It enhances the performance of the Walksnail Avatar HD system for various demanding applications.

Compatibility

The repeater is designed for the Walksnail Avatar HD System. It features a wide power input range from 9V to 26V and includes a USB port and a 4-pin 1.0mm pitch connector for integration and potential firmware updates.

FAQ

What is the Walksnail Video Repeater and who is it for?

The Walksnail Video Repeater is an accessory designed to enhance the video transmission range and stability for the Walksnail Avatar HD System. It's ideal for FPV pilots who require a more robust and extended video link for long-range flights or in environments with potential signal interference.

What are the key technical specifications of the Walksnail Video Repeater?

It operates on 5.15-5.30 GHz and 5.50-5.85 GHz frequencies, supports up to 1080p @ 100fps transmission, and features 7dBi gain antennas. Power input ranges from 9V to 26V, and it weighs 145g without antennas.

How does the dual-band operation benefit my FPV setup?

The dual-band capability (5.8G and 5.2G) allows the repeater to utilize different frequency bands, potentially reducing interference and improving signal reliability. This can lead to a more stable video feed, especially in crowded airspace or during long-distance flights.

Where can I buy the Walksnail Video Repeater with reliable delivery?

You can buy the Walksnail Video Repeater at HTDRONE. We are based in Poland and offer fast shipping within Poland. For international customers, we provide worldwide shipping via DHL, ensuring reliable and timely delivery of your FPV components.

What resolution and frame rates does the Walksnail Video Repeater support?

The Walksnail Video Repeater supports multiple high-definition resolutions and frame rates, including 1080p @ 100fps, 1080p @ 60fps, 720p @ 100fps, and 720p @ 60fps, ensuring a smooth and detailed video feed.
